Panasonic PT-D3500E

Ref.
No.
Part No. Part Name &
Description
Remarks
IC9810 C1BB00001099 I.C
[TRANSISTORS]
Q2001 UNR221100L TRANSISTOR
Q2501 UNR221100L TRANSISTOR
Q2503 UNR221100L TRANSISTOR
Q2505 UNR221100L TRANSISTOR
Q2507 UNR221100L TRANSISTOR
Q2508 2SB709A TRANSISTOR 2SB0709A
Q2509 2SB1218A TRANSISTOR
Q2510 B1CBHD000001 TRANSISTOR
Q2511 B1CBHD000001 TRANSISTOR
Q2512 2SB1218A TRANSISTOR
Q3000 2SD10300TL TRANSISTOR
Q3001 2SD10300TL TRANSISTOR
Q3002 B1CBHD000001 TRANSISTOR
Q3003 2SD1819A TRANSISTOR 2SD1819AW
Q3004 B1CBHD000001 TRANSISTOR
Q3005 2SD1819A TRANSISTOR 2SD1819AW
Q3006 2SB1218A TRANSISTOR
Q3007 2SB1218A TRANSISTOR
Q3008 2SD1819A TRANSISTOR 2SD1819AW
Q3009 2SB1218A TRANSISTOR
Q3010 2SD1819A TRANSISTOR 2SD1819AW
Q3011 2SB1218A TRANSISTOR
Q3012 2SD1819A TRANSISTOR 2SD1819AW
Q3013 2SB1218A TRANSISTOR
Q3014 2SD1819A TRANSISTOR 2SD1819AW
Q3015 2SB1218A TRANSISTOR
Q3016 2SD1819A TRANSISTOR 2SD1819AW
Q3017 UNR221100L TRANSISTOR
Q3018 UNR221100L TRANSISTOR
Q3019 UNR221100L TRANSISTOR
Q3020 UNR221100L TRANSISTOR
Q3021 B1CBHD000001 TRANSISTOR
Q3022 B1CBHD000001 TRANSISTOR
Q3031 UNR221100L TRANSISTOR
Q3032 2SD1819A TRANSISTOR 2SD1819AW
Q3033 2SB1218A TRANSISTOR
Q3605 B1CBHD000001 TRANSISTOR
Q3606 B1CBHD000001 TRANSISTOR
Q3607 UNR221100L TRANSISTOR
Q3608 B1DHDD000027 TRANSISTOR
Q3609 UNR221100L TRANSISTOR
Q3611 UNR221100L TRANSISTOR
Q3614 UNR221100L TRANSISTOR
Q3615 B1DHDD000027 TRANSISTOR
Q3619 2SD1819A TRANSISTOR 2SD1819AW
Q3621 2SD1819A TRANSISTOR 2SD1819AW
Q3622 B1DFED000017 TRANSISTOR
Q3623 2SD1819A TRANSISTOR 2SD1819AW
Q3627 2SB1218A TRANSISTOR
Q3628 2SB1218A TRANSISTOR
Q3629 2SD1819A TRANSISTOR 2SD1819AW
Q9801 UNR221100L TRANSISTOR
Q9802 UNR221100L TRANSISTOR
Q9803 UNR221100L TRANSISTOR
Q9804 2SD1819A TRANSISTOR 2SD1819AW
Q9805 2SB710A TRANSISTOR 2SB0710A
Q9806 2SB1218A TRANSISTOR
Q9807 UNR221100L TRANSISTOR
Q9808 UNR221100L TRANSISTOR
Q9809 2SD1979STX TRANSISTOR 2SD19790SL
Q9810 2SB1218A TRANSISTOR
Q9811 2SD1979STX TRANSISTOR 2SD19790SL
Q9812 2SB1218A TRANSISTOR
[DIODES]
D2001 MA157A DIODE MA3X157A
D2002 MA157A DIODE MA3X157A
D2003 MA157A DIODE MA3X157A
Ref.
No.
Part No. Part Name &
Description
Remarks
D2004 MA157A DIODE MA3X157A
D2005 LNJ308G8TRA LED
D2007 LNJ308G8TRA LED
D2008 LNJ308G8TRA LED
D2501 LNJ308G8TRA LED
D2503 LNJ308G8TRA LED
D2504 MA157A DIODE MA3X157A
D2505 LNJ208R8ARA LED
D2506 LNJ208R8ARA LED
D2507 B3AGB0000033 DIODE
D2508 MA152WK DIODE MA3X152E
D2509 MA152WK DIODE MA3X152E
D2510 LNJ308G8TRA LED
D2511 B3AGB0000033 DIODE
D2512 LNJ308G8TRA LED
D3000 MA8056M DIODE MAZ80560M
D3001 MA8056M DIODE MAZ80560M
D3002 MA8056M DIODE MAZ80560M
D3003 MA157A DIODE MA3X157A
D3004 MA157A DIODE MA3X157A
D3005 MA157A DIODE MA3X157A
D3009 MA157A DIODE MA3X157A
D3013 EZJZ0V80008B VARISTOR
D3014 EZJZ0V80008B VARISTOR
D3015 MA157A DIODE MA3X157A
D3016 MA157A DIODE MA3X157A
D3017 EZJZ0V80008B VARISTOR
D3018 EZJZ0V80008B VARISTOR
D3019 MA157A DIODE MA3X157A
D3020 MA157A DIODE MA3X157A
D3021 MA157A DIODE MA3X157A
D3022 MA157A DIODE MA3X157A
D3023 MA157A DIODE MA3X157A
D3024 MA157A DIODE MA3X157A
D3025 EZJZ0V171AA VARISTOR
D3026 MA8056M DIODE MAZ80560M
D3027 MA8056M DIODE MAZ80560M
D3036 MA2Z72000L DIODE
D3037 MA2Z72000L DIODE
D3040 EZJZ0V80008B VARISTOR
D3041 EZJZ0V80008B VARISTOR
D3042 EZJZ0V80008B VARISTOR
D3043 EZJZ0V80008B VARISTOR
D3044 EZJZ0V80008B VARISTOR
D3045 EZJZ0V80008B VARISTOR
D3046 EZJZ0V80008B VARISTOR
D3047 EZJZ0V80008B VARISTOR
D3048 MA8056M DIODE MAZ80560M
D3049 B0HCMM000013 DIODE
D3050 MAZY12000L DIODE
D3611 B0JCPD000026 DIODE
D3616 B0JCPD000026 DIODE
D3620 B0JCPD000026 DIODE
D3621 B0JCPD000026 DIODE
D3622 B0JCPD000026 DIODE
D3623 B0JCPD000026 DIODE
D3624 B0JCPD000026 DIODE
D3625 B0JCPD000026 DIODE
D9801 MA157A DIODE MA3X157A
D9802 MA157A DIODE MA3X157A
D9803 MA8056M DIODE MAZ80560M
D9804 MA8056M DIODE MAZ80560M
D9805 MA8056M DIODE MAZ80560M
D9806 MA8056M DIODE MAZ80560M
D9807 MA8056M DIODE MAZ80560M
D9808 MA8056M DIODE MAZ80560M
D9809 MA8056M DIODE MAZ80560M
D9810 MA8056M DIODE MAZ80560M
D9811 D4ED1270A006 VARISTOR
D9812 D4ED1270A006 VARISTOR
D9813 D4ED1120A002 VARISTOR
D9814 D4ED1120A002 VARISTOR
D9815 D4ED1120A002 VARISTOR
83
PT-D3500U / PT-D3500E
