Panasonic PT-D3500E - Page 93

Ref.
No.
Part No. Part Name &
Description
Remarks
C3781 F2G1E4R70007 CAPACITOR
C3785 F2G0J4700010 CAPACITOR
C3788 EEEHB0G101R E 100UF, 4V
C3790 F2G0J1010013 CAPACITOR
C3791 F2G0J1010013 CAPACITOR
C3792 F2G1E4R70007 CAPACITOR
C3794 ECJ1VF1C104Z C 0.1UF, Z, 16V
C3795 ECJ1VF1C104Z C 0.1UF, Z, 16V
C3799 ECJ1VB1H103K C 0.01UF, K, 50V
C3800 ECJ1VF1C104Z C 0.1UF, Z, 16V
C3803 ECJ1VF1A105Z C 1UF, Z, 50V
C3804 ECJ1VB0J105K C 1UF,Z, 6.3V
C3805 ECJ1VB0J105K C 1UF,Z, 6.3V
C3806 ECJ1VF1C104Z C 0.1UF, Z, 16V
C3883 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9602 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9701 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9801 ECJ1VF1C105Z C 0.01UF, Z, 16V
C9802 ECJ1VF1C105Z C 0.01UF, Z, 16V
C9803 ECJ1VF1C105Z C 0.01UF, Z, 16V
C9804 EEEHB0J470R E 47UF, 6.3V
C9805 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9806 ECJ1VF1C105Z C 0.01UF, Z, 16V
C9807 ECJ1VF1C105Z C 0.01UF, Z, 16V
C9808 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9809 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9810 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9811 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9812 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9813 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9814 ECJ1VF1C105Z C 0.01UF, Z, 16V
C9815 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9816 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9817 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9818 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9819 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9820 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9821 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9822 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9823 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9824 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9825 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9826 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9827 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9828 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9829 ECJ2YF1C225Z C 2.2UF, Z, 16V
C9830 EEEHB1E330P E 33UF, 25V
C9831 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9832 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9833 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9834 EEEHP1C100R E 10UF, 16V
C9835 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9837 EEEHB1C101P CAPACITOR
C9838 EEEHB1C101P CAPACITOR
C9840 EEEHP1C100R E 10UF, 16V
C9841 EEEHB0J470R E 47UF, 6.3V
C9842 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9843 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9844 ECJ3YF1C475Z C 4.7UF, Z, 16V
C9845 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9846 EEEHB1C220R CAPACITOR
C9847 ECJ2FF1A106Z C 10UF, 10V
C9848 ECJ2FF1A106Z C 10UF, 10V
C9951 ECJ1VF1C104Z C 0.1UF, Z, 16V
C9952 F2G0J4700010 CAPACITOR
[OTHERS]
A1 K1KA03BA0086 3P CONNECTOR
A3 K1MN18B00062 18P CONNECTOR
A5 K1KA11BA0086 11P CONNECTOR
A7 K1KA02BA0085 2P CONNECTOR
A10 K1KA02B00247 2P CONNECTOR
Ref.
No.
Part No. Part Name &
Description
Remarks
A11 K1KA03AA0104 3P CONNECTOR
A21 K1KA04BA0014 4P CONNECTOR
A22 K1KA08BA0047 8P CONNECTOR
A23 K1KA08BA0047 8P CONNECTOR
A27 K1KA04BA0047 4P CONNECTOR
A29 K1KA03BA0047 3P CONNECTOR
A30 K1KA04AA0104 4P CONNECTOR
A31 K1KA03AA0104 3P CONNECTOR
A40 K1KA08BA0086 8P CONNECTOR
A41 K1MN16B00012 16P CONNECTOR
A42 K1KA02AA0104 2P CONNECTOR
A43 K1KA14BA0051 11P CONNECTOR
A44 K1MN04B00008 4P CONNECTOR
A45 K1MN04B00008 4P CONNECTOR
A71 K1KA06A00454 6P CONNECTOR
A100 K1KA06A00454 6P CONNECTOR
B2501 BCR20V4 BATTERY HOLDER
CF9701 D4CC1103A037 THERMISTOR
CW1 K1KA03AA0263 3P CONNECTOR
J1 K1MN18B00062 18P CONNECTOR
R1 K1KA03BA0086 3P CONNECTOR
T1 K1KA03AA0104 3P CONNECTOR
JK2001 K2LC108B0064 TERMINAL
JK2003 K1FB124B0026 TERMINAL
JK3001 K1CB205B0006 TERMINAL
JK3002 K1FB115B0103 TERNINAL CONNECTOR
JK3003 K1QBB3AB0007 TERMINAL
JK3004 K1QBB2AB0018 TERMINAL
JK9801 K2HC204B0002 CONNECTOR
JK9802 K2HC204B0002 CONNECTOR
JK9803 K2HA408B0084 CONNECTOR
JK9804 TJS1A7250 HEADHONE JACK K2HC103B0093
JK9805 K1FB109B0070 CONNECTOR
JK9806 K1FB109B0070 CONNECTOR
RM2001 B3RAD0000100 REMOTE CONTROL
RECEIVER
RM9951 B3RAD0000100 REMOTE CONTROL
RECEIVER
SW2501 EVQPLHA15 SWITCH
SW2502 EVQPLHA15 SWITCH
SW2503 EVQPLHA15 SWITCH
SW2504 EVQPLHA15 SWITCH
SW2505 EVQPLHA15 SWITCH
SW2506 EVQPLHA15 SWITCH
SW2507 EVQPLHA15 SWITCH
SW2508 EVQPLHA15 SWITCH
SW2509 EVQPLHA15 SWITCH
SW2510 EVQPLHA15 SWITCH
SW2511 EVQPLHA15 SWITCH
SW2512 EVQPLHA15 SWITCH
X2002 H1A6605B0004 CRYSTAL
X2003 H0J250500042 CRYSTAL
X2501 H0J983400016 CRYSTAL
X2502 H0J327200114 CRYSTAL
X3000 H0J202500002 CRYSTAL
X3002 H1A6005B0012 CRYSTAL
TXN/A2VKA3 CIRCUIT BOARD A
TXN/J1VKA3 CIRCUIT BOARD J
TXN/R1VKA3 CIRCUIT BOARD R
TXN/T1VKA3 CIRCUIT BOARD T
TXNCW1VKA3 CIRCUIT BOARD CW
93
PT-D3500U / PT-D3500E
