Chapter 2 Getting Started — Setting up
ENGLISH - 45
For PT-DZ16K2
r When the image aspect ratio is 16:9
(Unit: m)
Lens type Zoom lens
Projection lens Model No. ET-D75LE6 ET-D75LE10 ET-D75LE20 ET-D75LE30 ET-D75LE40 ET-D75LE8
Throw ratio
*1
0.9-1.1:1 1.3-1.7:1 1.7-2.4:1 2.4-4.7:1 4.6-7.4:1 7.3-13.8:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width (SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
1.78 (70") 0.872 1.550 1.40 1.67 1.96 2.53 2.53 3.68 3.66 7.14 7.07 11.36 11.16 21.28
2.03 (80") 0.996 1.771 1.61 1.92 2.25 2.91 2.91 4.23 4.20 8.19 8.10 13.00 12.81 24.37
2.29 (90") 1.121 1.992 1.82 2.17 2.54 3.29 3.28 4.77 4.74 9.23 9.13 14.65 14.46 27.46
2.54 (100") 1.245 2.214 2.03 2.42 2.83 3.67 3.65 5.31 5.28 10.28 10.16 16.29 16.11 30.55
3.05 (120") 1.494 2.657 2.44 2.92 3.42 4.42 4.40 6.40 6.35 12.37 12.23 19.58 19.41 36.73
3.81 (150") 1.868 3.321 3.07 3.67 4.29 5.55 5.52 8.03 7.97 15.50 15.32 24.52 24.36 46.00
5.08 (200") 2.491 4.428 4.11 4.92 5.75 7.44 7.39 10.74 10.67 20.73 20.48 32.75 32.61 61.46
6.35 (250") 3.113 5.535 5.15 6.17 7.21 9.33 9.26 13.46 13.36 25.96 25.64 40.97 40.86 76.91
7.62 (300") 3.736 6.641 6.19 7.41 8.67 11.21 11.13 16.17 16.06 31.18 30.80 49.20 49.11 92.37
8.89 (350") 4.358 7.748 7.23 8.66 10.13 13.10 12.99 18.88 18.75 36.41 35.96 57.43 57.35 107.82
10.16 (400") 4.981 8.855 8.28 9.91 11.59 14.99 14.86 21.60 21.45 41.64 41.12 65.65 65.60 123.28
12.70 (500") 6.226 11.069 10.36 12.40 14.51 18.76 18.60 27.03 26.84 52.09 51.44 82.11 82.10 154.19
15.24 (600") 7.472 13.283 12.44 14.90 17.44 22.54 22.33 32.46 32.23 62.54 61.76 98.56 98.60 185.10
25.40 (1000") 12.453 22.138 20.77 24.88 29.12 37.63 37.28 54.17 53.79 104.36 103.05 164.38 164.59 ―
Lens type Fixed-focus lens
Projection lens Model No. ET-D75LE90
*2
ET-D75LE50
Throw ratio
*1
0.36:1 0.7:1
Projected image size
Projection
distance
(L1)
Distance between projector and
screen
Projection
distance (L)
Diagonal (SD)
Height
(SH)
Width (SW) (L4) (A1) Fixed
1.78 (70") 0.872 1.550 ― ― ― 1.04
2.03 (80") 0.996 1.771 ― ― ― 1.20
2.29 (90") 1.121 1.992 ― ― ― 1.36
2.54 (100") 1.245 2.214 ― ― ― 1.51
3.05 (120") 1.494 2.657 0.97 -0.04 0.27 - 0.44 1.83
3.81 (150") 1.868 3.321 1.21 0.20 0.36 - 0.58 2.31
5.08 (200") 2.491 4.428 1.60 0.60 0.52 - 0.81 3.10
6.35 (250") 3.113 5.535 2.00 0.99 0.68 - 1.04 3.89
7.62 (300") 3.736 6.641 2.39 1.39 0.83 - 1.27 4.68
8.89 (350") 4.358 7.748 2.79 1.78 0.99 - 1.50 5.48
10.16 (400") 4.981 8.855 3.19 2.18 1.15 - 1.73 6.27
12.70 (500") 6.226 11.069 3.98 2.97 1.47 - 2.19 7.85
15.24 (600") 7.472 13.283 4.77 3.76 1.78 - 2.65 9.44
25.40 (1000") 12.453 22.138 ― ― ― 15.78
*1 The throw ratio is based on the value during projection with the projected image size of 3.81 m (150").
*2 When the xed-focus lens (Model No.: ET-D75LE90) is attached, the projection relation between the screen and the projector differs from that of
other lenses. Refer to “For xed-focus lens (Model No.: ET-D75LE90)” (x page 35) for details.
