2.56. INPUT RESOLUTION - TOTAL DOTS
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 44h 3Ah
Character A D Z Z ; V T D :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6, *7, *8)
330 331
Hexadecimal 30h 33h 33h 30h 30h 33h 33h 31h
Character 0 3 3 0 0 3 3 1
4095 4096
Hexadecimal 34h 30h 39h 35h 34h 30h 39h 36h
Character 4 0 9 5 4 0 9 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 44h 3Ah *1 *3 *5 *7 03h
Character V T D : *2 *4 *6 *8
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
VIDEO S-VIDEO RGB1 RGB2 YP
B
P
R
1 YP
B
P
R
2DVI
No No Yes Yes No No No
Notes:
- The maximum value that can be actually set changes according to the input signal or the input resolution
settings, etc.
- Calls back ER402 when the value of less than number in which 30 is added to number of display dots is specified.
2.57. INPUT RESOLUTION - DISPLAY DOTS
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 44h 44h 3Ah
Character A D Z Z ; V D D :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6, *7, *8)
300 301
Hexadecimal 30h 33h 30h 30h 30h 33h 30h 31h
Character 0 3 0 0 0 3 0 1
2065 2066
Hexadecimal 32h 30h 36h 35h 32h 30h 36h 36h
Character 2 0 6 5 2 0 6 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 44h 44h 3Ah *1 *3 *5 *7 03h
Character V D D : *2 *4 *6 *8
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
VIDEO S-VIDEO RGB1 RGB2 YP
B
P
R
1 YP
B
P
R
2DVI
No No Yes Yes No No No
Notes:
- The maximum value that can be actually set changes according to the input signal or the input resolution
settings, etc.
- Calls back ER402 when the value of more than number in which 30 is subtracted from number of total dots is
specified.
