2.58. INPUT RESOLUTION - TOTAL LINES
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 4Ch 3Ah
Character A D Z Z ; V T L :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6, *7, *8)
310 311
Hexadecimal 30h 33h 31h 30h 30h 33h 31h 31h
Character 0 3 1 0 0 3 1 1
2046 2047
Hexadecimal 24h 30h 34h 36h 32h 30h 34h 37h
Character 2 0 4 6 2 0 4 7
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 4Ch 3Ah *1 *3 *5 *7 03h
Character V T L : *2 *4 *6 *8
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
VIDEO S-VIDEO RGB1 RGB2 YP
B
P
R
1 YP
B
P
R
2DVI
No No Yes Yes No No No
Notes:
- The maximum value that can be actually set changes according to the input signal or the input resolution
settings, etc.
- Calls back ER402 when the value of less than number in which 10 is added to number of display lines is
specified.
2.59. INPUT RESOLUTION - DISPLAY LINES
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 44h 4Ch 3Ah
Character A D Z Z ; V D L :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6, *7, *8)
300 301
Hexadecimal 30h 33h 30h 30h 30h 33h 30h 31h
Character 0 3 0 0 0 3 0 1
1199 1200
Hexadecimal 21h 31h 39h 39h 31h 32h 30h 30h
Character 1 1 9 9 1 2 0 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 44h 4Ch 3Ah *1 *3 *5 *7 03h
Character V D L : *2 *4 *6 *8
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
VIDEO S-VIDEO RGB1 RGB2 YP
B
P
R
1 YP
B
P
R
2DVI
No No Yes Yes No No No
Notes:
- The maximum value that can be actually set changes according to the input signal or the input resolution
settings, etc.
- Calls back ER402 when the value of more than number in which 10 is subtracted from number of total lines is
specified.
