2.60. CLAMP POSITION
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 4Ch 54h 3Ah
Character A D Z Z ; V L T :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
253 254 255
Hexadecimal 32h 35h 33h 32h 35h 34h 32h 35h 35h
Character 2 5 3 2 5 4 2 5 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 4Ch 54h 3Ah *1 *3 *5 03h
Character V L T : *2 *4 *6
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
VIDEO S-VIDEO RGB1 RGB2 YP
B
P
R
1 YP
B
P
R
2DVI
No No Yes Yes Yes Yes No
2.61. KEYSTONE
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Bh 53h 3Ah
Character A D Z Z ; O K S :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
-127 -126 -125
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
+125 +126 +127
Hexadecimal 32h 35h 32h 32h 35h 33h 32h 35h 34h
Character 2 5 2 2 5 3 2 5 4
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Bh 53h 3Ah *1 *3 *5 03h
Character O K S : *2 *4 *6
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No Ye s No Yes Yes No Yes Yes
Note:
- For PT-DZ6710*, ER401 is returned.
2.62. SUB KEYSTONE
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 53h 4Bh 3Ah
Character A D Z Z ; O S K :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
-63 -62 -61
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
+61 +62 +63
Hexadecimal 31h 32h 34h 31h 32h 35h 31h 32h 36h
Character 1 2 4 1 2 5 1 2 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 4Bh 3Ah *1 *3 *5 03h
Character O S K : *2 *4 *6
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No Ye s No Yes Yes No Yes Yes
Notes:
- For PT-DZ6710*, ER401 is returned.
- When "0" is set to KEYSTONE, ER401 is returned.
- According to KEYSTONE settings, there is a case that does not operate even if the SUB KEYSTONE value is
changed.
