Panasonic PT-DW6300ES - Page 176

32/80
2.79. BLANKING - UPPER
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 44h 42h 55h 3Ah
Character A D Z Z ; D B U :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
PT-D6000*
381 382 383
Hexadecimal 33h 38h 31h 33h 38h 32h 33h 38h 33h
Character 3 8 1 3 8 2 3 8 3
PT-DW6300*
397 398 399
Hexadecimal 33h 39h 37h 33h 39h 38h 33h 39h 39h
Character 3 9 7 3 9 8 3 9 9
PT-DZ6710*/DZ6700*
597 598 599
Hexadecimal 35h 39h 37h 35h 39h 38h 35h 39h 39h
Character 5 9 7 5 9 8 5 9 9
Note:
- The maximum value that can be set changes according to settings of the input signal, the aspect and the zoom.
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 44h 42h 55h 3Ah *1 *3 *5 03h
Character D B U : *2 *4 *6
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
2.80. BLANKING - LOWER
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 44h 42h 42h 3Ah
Character A D Z Z ; D B B :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
PT-D6000*
381 382 383
Hexadecimal 33h 38h 31h 33h 38h 32h 33h 38h 33h
Character 3 8 1 3 8 2 3 8 3
PT-DW6300*
397 398 399
Hexadecimal 33h 39h 37h 33h 39h 38h 33h 39h 39h
Character 3 9 7 3 9 8 3 9 9
PT-DZ6710*/DZ6700*
597 598 599
Hexadecimal 35h 39h 37h 35h 39h 38h 35h 39h 39h
Character 5 9 7 5 9 8 5 9 9
Note:
- The maximum value that can be set changes according to settings of the input signal, the aspect and the zoom.
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 44h 42h 42h 3Ah *1 *3 *5 03h
Character D B B : *2 *4 *6
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
