2.81. BLANKING - RIGHT
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 44h 42h 52h 3Ah
Character A D Z Z ; D B R :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
PT-D6000*
509 510 511
Hexadecimal 35h 30h 39h 35h 31h 30h 35h 31h 31h
Character 5 0 9 5 1 0 5 1 1
PT-DW6300*
637 638 639
Hexadecimal 36h 33h 37h 36h 33h 38h 36h 33h 39h
Character 6 3 7 6 3 8 6 3 9
PT-DZ6710*/DZ6700*
957 958 959
Hexadecimal 39h 35h 37h 39h 35h 38h 39h 35h 39h
Character 9 5 7 9 5 8 9 5 9
Note:
- The maximum value that can be set changes according to settings of the input signal, the aspect and the zoom.
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 44h 42h 52h 3Ah *1 *3 *5 03h
Character D B R : *2 *4 *6
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
2.82. BLANKING - LEFT
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 44h 42h 4Ch 3Ah
Character A D Z Z ; D B L :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
PT-D6000*
509 510 511
Hexadecimal 35h 30h 39h 35h 31h 30h 35h 31h 31h
Character 5 0 9 5 1 0 5 1 1
PT-DW6300*
637 638 639
Hexadecimal 36h 33h 37h 36h 33h 38h 36h 33h 39h
Character 6 3 7 6 3 8 6 3 9
PT-DZ6710*/DZ6700*
957 958 959
Hexadecimal 39h 35h 37h 39h 35h 38h 39h 35h 39h
Character 9 5 7 9 5 8 9 5 9
Note:
- The maximum value that can be set changes according to settings of the input signal, the aspect and the zoom.
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 44h 42h 4Ch 3Ah *1 *3 *5 03h
Character D B L : *2 *4 *6
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
