78/80
3. Extended Control Command
Start (STX) ID Command Parameters End (ETX)
1 byte 1 byte 1 byte or 2 bytes Undefined length 1 byte
ID of the extended control command
ID Hexadecimal
(1 byte)
ID Hexadecimal
(1 byte)
ID Hexadecimal
(1 byte)
ID Hexadecimal
(1 byte)
ALL 00
ID23 17 ID46 2E Group E 84
ID1 01
ID24 18 ID47 2F Group F 85
ID2 02
ID25 19 ID48 30 Group G 86
ID3 03
ID26 1A ID49 31 Group H 87
ID4 04
ID27 1B ID50 32 Group I 88
ID5 05
ID28 1C ID51 33 Group J 89
ID6 06
ID29 1D ID52 34 Group K 8A
ID7 07
ID30 1E ID53 35 Group L 8B
ID8 08
ID31 1F ID54 36 Group M 8C
ID9 09
ID32 20 ID55 37 Group N 8D
ID10 0A
ID33 21 ID56 38 Group O 8E
ID11 0B
ID34 22 ID57 39 Group P 8F
ID12 0C
ID35 23 ID58 3A Group Q 90
ID13 0D
ID36 24 ID59 3B Group R 91
ID14 0E
ID37 25 ID60 3C Group S 92
ID15 0F
ID38 26 ID61 3D Group T 93
ID16 10
ID39 27 ID62 3E Group U 94
ID17 11
ID40 28 ID63 3F Group V 95
ID18 12
ID41 29 ID64 40 Group W 96
ID19 13
ID42 2A Group A 80 Group X 97
ID20 14
ID43 2B Group B 81 Group Y 98
ID21 15
ID44 2C Group C 82 Group Z 99
ID22 16
ID45 2D Group D 83
3.1. Lens Control
Hexadecimal 02h *1 B1h 7Ch *2 *3 *4 03h
Remarks STX ID Command Parameters ETX
Parameters (*2)
LENS SHIFT H LENS SHIFT V LENS FOCUS LENS ZOOM
Hexadecimal 00h 01h 02h 03h
Parameters (*3)
Slowly Normal Fast HOME POSITION *
Hexadecimal 00h 01h 02h 80h
Parameters (*4)
Right / Up / Forward / In / Cancel Left / Down / Backward / Out / Start
Hexadecimal 00h 01h
Note:
- HOME POSITION is available only when parameters (*2) is LENS SHIFT H (00h) or LENS SHIFT V (01h).
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h *5 B3h 7Ch *2 *3 *4 03h
STX ID Callback Parameters ETX
In the period when the command cannot be accepted
Hexadecimal 02h *5 FFh 03h
STX ID Error ETX
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
Yes No No Ye s No Yes Yes Ye s
To Next Page
