Panasonic PT-EW630U

Ref. Part No. Description Note Ref. Part No. Description Note
SPL-25
Electrical Parts List
PT-EX600U / PT-EX600E / PT-EX600UL / PT-EX630EL
PT-EW630U / PT-EW630E / PT-EW630UL / PT-EW630EL
C8810 3034093426 CERAMIC 0.1U K 16V
C8812 3033583215 CERAMIC 10U K 6.3V
C8813 4034587219 ELECT 100U M 6.3V
C8814 3034093426 CERAMIC 0.1U K 16V
C8817 3034093426 CERAMIC 0.1U K 16V
C8818 3034093426 CERAMIC 0.1U K 16V
C8819 3032763113 CERAMIC 33P J 50V
C8820 3032763113 CERAMIC 33P J 50V
C8821 3033969613 CERAMIC 1U K 25V
C8822 4034564210 CERAMIC 470P J 50V
C8824 3034093426 CERAMIC 0.1U K 16V
C8827 3034093426 CERAMIC 0.1U K 16V
C8831 3034093426 CERAMIC 0.1U K 16V
C8832 3034093426 CERAMIC 0.1U K 16V
C8833 4034551012 CERAMIC 1U K 10V
C8841 3034540910 CERAMIC 100P J 50V
C8842 3034540910 CERAMIC 100P J 50V
C8847 3033583215 CERAMIC 10U K 6.3V
C8848 3032844317 CERAMIC 0.022U K 50V
C9875 3033058812 CERAMIC 47P J 50V
C9878 3034420410 CERAMIC 0.022U K 25V
C9883 3033921215 ELECT 47U M 6.3V
C9884 3034093426 CERAMIC 0.1U K 16V
D001 3072350816 DIODE 1SS387 TPL3
D002 3072350816 DIODE 1SS387 TPL3
D1002 3072094512 ZD UDZS-TE-176.8B
D1003 3072542716 DIODE CMS16
D1004 3072542716 DIODE CMS16
D1005 3072094512 ZD UDZS-TE-176.8B
D1024 3072091214 ZD UDZS-TE-176.2B
D1026 3072091214 ZD UDZS-TE-176.2B
D1031 3072105416 DIODE RB551V-30-TE-17
D1091 3011506014 MT-GLAZE 0.000 ZA 1/10W
D1091 3011506014 MT-GLAZE 0.000 ZA 1/10W
D1092 3072055216 DIODE RB521S-30-TE61
D1451 3071490810 DIODE 1SS355-TE-17
D1454 3071490810 DIODE 1SS355-TE-17
D1802 3072091214 ZD UDZS-TE-176.2B
D1803 3072091214 ZD UDZS-TE-176.2B
D1804 3072091214 ZD UDZS-TE-176.2B
D1805 3072091214 ZD UDZS-TE-176.2B
D202 3072066311 ZD UDZS-TE-175.1B
D2043 3071490810 DIODE 1SS355-TE-17
D2045 3071490810 DIODE 1SS355-TE-17
D276 3071490810 DIODE 1SS355-TE-17
D353 3071490810 DIODE 1SS355-TE-17
D354 3071490810 DIODE 1SS355-TE-17
D355 3071490810 DIODE 1SS355-TE-17
D356 3071490810 DIODE 1SS355-TE-17
D357 3071490810 DIODE 1SS355-TE-17
D358 3071490810 DIODE 1SS355-TE-17
D4461 3072094512 ZD UDZS-TE-176.8B
D5271 3072105416 DIODE RB551V-30-TE-17
D5503 3072091214 ZD UDZS-TE-176.2B
D5523 3072091214 ZD UDZS-TE-176.2B
D5531 3071490810 DIODE 1SS355-TE-17
D5532 3071490810 DIODE 1SS355-TE-17
D5621 3071490810 DIODE 1SS355-TE-17
D5622 3072542716 DIODE CMS16
D5641 4080627201 DIODE 1SS355
D5801 3072091214 ZD UDZS-TE-176.2B
D5802 3072091214 ZD UDZS-TE-176.2B
D5803 3072091214 ZD UDZS-TE-176.2B
D5850 3072091214 ZD UDZS-TE-176.2B
D5851 3072091214 ZD UDZS-TE-176.2B
D5852 3072091214 ZD UDZS-TE-176.2B
D5853 3072091214 ZD UDZS-TE-176.2B
D5854 3072091214 ZD UDZS-TE-176.2B
D5856 3072091214 ZD UDZS-TE-176.2B
D5891 3072350816 DIODE 1SS387 TPL3
D5892 3072350816 DIODE 1SS387 TPL3
D5893 3072350816 DIODE 1SS387 TPL3
D592 3071490810 DIODE 1SS355-TE-17
D6503 3072312210 ZENER DIODE UDZS13B-TE-17
D6523 3072312210 ZENER DIODE UDZS13B-TE-17
D6603 3072542716 DIODE CMS16
D6604 3071490810 DIODE 1SS355-TE-17
D6623 3071490810 DIODE 1SS355-TE-17
D6676 3071490810 DIODE 1SS355-TE-17
D7701 3072542716 DIODE CMS16
D7721 3072542716 DIODE CMS16
D7824 3071490810 DIODE 1SS355-TE-17
D7826 3071490810 DIODE 1SS355-TE-17
D7827 3071490810 DIODE 1SS355-TE-17
D7828 3071490810 DIODE 1SS355-TE-17
D7829 3071490810 DIODE 1SS355-TE-17
D7850 3071490810 DIODE 1SS355-TE-17
D7851 3071490810 DIODE 1SS355-TE-17
D7852 3071490810 DIODE 1SS355-TE-17
D7853 3071490810 DIODE 1SS355-TE-17
D7854 3071490810 DIODE 1SS355-TE-17
D7855 3071490810 DIODE 1SS355-TE-17
D7856 3071490810 DIODE 1SS355-TE-17
D7857 3071490810 DIODE 1SS355-TE-17
D7858 3071490810 DIODE 1SS355-TE-17
D7859 3071490810 DIODE 1SS355-TE-17
D7860 3071490810 DIODE 1SS355-TE-17
D7861 3071490810 DIODE 1SS355-TE-17
D7960 3071490810 DIODE 1SS355-TE-17
D7961 3071490810 DIODE 1SS355-TE-17
D7962 3071490810 DIODE 1SS355-TE-17
D7963 3071490810 DIODE 1SS355-TE-17
D7964 3071490810 DIODE 1SS355-TE-17
D7965 3071490810 DIODE 1SS355-TE-17
D7966 3071490810 DIODE 1SS355-TE-17
D7967 3071490810 DIODE 1SS355-TE-17
D7968 3071490810 DIODE 1SS355-TE-17
D7969 3071490810 DIODE 1SS355-TE-17
D8076 3072281011 LED SML-310MT-M-T86
D8161 3072055216 DIODE RB521S-30-TE61
D8162 3072055216 DIODE RB521S-30-TE61
D8163 3011506014 MT-GLAZE 0.000 ZA 1/10W
D8163 3011506014 MT-GLAZE 0.000 ZA 1/10W
D8164 3072055216 DIODE RB521S-30-TE61
D851 3072091214 ZD UDZS-TE-176.2B
D852 3072091214 ZD UDZS-TE-176.2B
D853 3072091214 ZD UDZS-TE-176.2B
D854 3072091214 ZD UDZS-TE-176.2B
D855 3072091214 ZD UDZS-TE-176.2B
D856 3072091214 ZD UDZS-TE-176.2B
D857 3072091214 ZD UDZS-TE-176.2B
D8902 3072350816 DIODE 1SS387 TPL3
D9901 3071490810 DIODE 1SS355-TE-17
D9902 3071490810 DIODE 1SS355-TE-17
D9903 3071490810 DIODE 1SS355-TE-17
D9904 3071490810 DIODE 1SS355-TE-17
FB5801 9450866044 IMPEDANCE,470 OHM P
FB5802 9450866044 IMPEDANCE,470 OHM P
FB5803 9450866044 IMPEDANCE,470 OHM P
FB7870 9450866044 IMPEDANCE,470 OHM P
FB7871 9450866044 IMPEDANCE,470 OHM P
FB7873 9450866044 IMPEDANCE,470 OHM P
FB7874 9450866044 IMPEDANCE,470 OHM P
FB7875 9450866044 IMPEDANCE,470 OHM P
FB7876 9450866044 IMPEDANCE,470 OHM P
FB7877 9450866044 IMPEDANCE,470 OHM P
FB7878 9450866044 IMPEDANCE,470 OHM P
FB7879 9450866044 IMPEDANCE,470 OHM P
FB7880 9450866044 IMPEDANCE,470 OHM P
FB7881 9450866044 IMPEDANCE,470 OHM P
IC001 4107311908 IC TPA3111D1PWPR
IC1003 3105176809 IC TC74LVX4053FT
