Ref. Part No. Description Note Ref. Part No. Description Note
SPL-38
Electrical Parts List
PT-EX600U / PT-EX600E / PT-EX600UL / PT-EX630EL
PT-EW630U / PT-EW630E / PT-EW630UL / PT-EW630EL
RB2322 9450360986 R-NETWORK 47X4 1/32W
RB311 9450360986 R-NETWORK 47X4 1/32W
RB312 9450360986 R-NETWORK 47X4 1/32W
RB313 9450360986 R-NETWORK 47X4 1/32W
RB314 9450360986 R-NETWORK 47X4 1/32W
RB316 9450360986 R-NETWORK 47X4 1/32W
RB317 9450490690 R-NETWORK 33X4 1/16W
RB318 9450490690 R-NETWORK 33X4 1/16W
RB319 9450490690 R-NETWORK 33X4 1/16W
RB321 9450490690 R-NETWORK 33X4 1/16W
RB322 9450490690 R-NETWORK 33X4 1/16W
RB323 9450490690 R-NETWORK 33X4 1/16W
RB324 9450360986 R-NETWORK 47X4 1/32W
RB326 9450360986 R-NETWORK 47X4 1/32W
RB327 9450360986 R-NETWORK 47X4 1/32W
RB328 9450360986 R-NETWORK 47X4 1/32W
RB329 9450360986 R-NETWORK 47X4 1/32W
RB331 9450360986 R-NETWORK 47X4 1/32W
RB332 9450360986 R-NETWORK 47X4 1/32W
RB333 9450360986 R-NETWORK 47X4 1/32W
RB334 9450360986 R-NETWORK 47X4 1/32W
RB336 9450360986 R-NETWORK 47X4 1/32W
RB337 9450360986 R-NETWORK 47X4 1/32W
RB339 9450360986 R-NETWORK 47X4 1/32W
RB406 9450345051 R-NETWORK 22X4 1/32W
RB407 9450345051 R-NETWORK 22X4 1/32W
RB408 9450345051 R-NETWORK 22X4 1/32W
RB409 9450345051 R-NETWORK 22X4 1/32W
RB411 9450345051 R-NETWORK 22X4 1/32W
RB412 9450345051 R-NETWORK 22X4 1/32W
RB413 9450345051 R-NETWORK 22X4 1/32W
RB414 9450345051 R-NETWORK 22X4 1/32W
RB416 9450345051 R-NETWORK 22X4 1/32W
RB417 9450345051 R-NETWORK 22X4 1/32W
RB418 9450345051 R-NETWORK 22X4 1/32W
RB419 9450345051 R-NETWORK 22X4 1/32W
RB421 9450345051 R-NETWORK 22X4 1/32W
RB422 9450345051 R-NETWORK 22X4 1/32W
RB423 9450345051 R-NETWORK 22X4 1/32W
RB424 9450345051 R-NETWORK 22X4 1/32W
RB426 9450345051 R-NETWORK 22X4 1/32W
RB427 9450345051 R-NETWORK 22X4 1/32W
RB4401 9450345051 R-NETWORK 22X4 1/32W
RB4402 9450345051 R-NETWORK 22X4 1/32W
RB4403 9450345051 R-NETWORK 22X4 1/32W
RB4404 9450345051 R-NETWORK 22X4 1/32W
RB4405 9450345051 R-NETWORK 22X4 1/32W
RB4406 9450345051 R-NETWORK 22X4 1/32W
RB4407 9450345051 R-NETWORK 22X4 1/32W
RB4408 9450345051 R-NETWORK 22X4 1/32W
RB4409 9450345051 R-NETWORK 22X4 1/32W
RB4411 9450345051 R-NETWORK 22X4 1/32W
RB4412 9450345051 R-NETWORK 22X4 1/32W
RB4413 9450345051 R-NETWORK 22X4 1/32W
RB4414 9450345051 R-NETWORK 22X4 1/32W
RB4415 9450345051 R-NETWORK 22X4 1/32W
RB4416 9450345051 R-NETWORK 22X4 1/32W
RB4417 9450345051 R-NETWORK 22X4 1/32W
RB4418 9450345051 R-NETWORK 22X4 1/32W
RB4419 9450345051 R-NETWORK 22X4 1/32W
RB4420 9450360979 R-NETWORK 10KX4 1/32W
RB4421 9450360986 R-NETWORK 47X4 1/32W
RB501 9450363529 R-NETWORK 0X4 1/32W
RB502 9450363529 R-NETWORK 0X4 1/32W
RB503 9450363529 R-NETWORK 0X4 1/32W
RB531 9450363529 R-NETWORK 0X4 1/32W
RB532 9450363529 R-NETWORK 0X4 1/32W
RB533 9450363529 R-NETWORK 0X4 1/32W
RB561 9450363529 R-NETWORK 0X4 1/32W
RB562 9450363529 R-NETWORK 0X4 1/32W
RB563 9450363529 R-NETWORK 0X4 1/32W
RB8001 9450345051 R-NETWORK 22X4 1/32W
RB8002 9450345051 R-NETWORK 22X4 1/32W
RB8003 9450345051 R-NETWORK 22X4 1/32W
RB8004 9450345051 R-NETWORK 22X4 1/32W
RB8005 9450345051 R-NETWORK 22X4 1/32W
RB8006 9450345051 R-NETWORK 22X4 1/32W
RB8007 9450345051 R-NETWORK 22X4 1/32W
RB8008 9450345051 R-NETWORK 22X4 1/32W
RB8009 9450345051 R-NETWORK 22X4 1/32W
RB8010 9450345051 R-NETWORK 22X4 1/32W
RB8038 9450490690 R-NETWORK 33X4 1/16W
RB8039 9450490690 R-NETWORK 33X4 1/16W
RB8041 9450490690 R-NETWORK 33X4 1/16W
RB8042 9450490690 R-NETWORK 33X4 1/16W
RB8043 9450490690 R-NETWORK 33X4 1/16W
RB8044 9450490690 R-NETWORK 33X4 1/16W
RB831 9450360979 R-NETWORK 10KX4 1/32W
RB832 9450360979 R-NETWORK 10KX4 1/32W
RB836 9450360979 R-NETWORK 10KX4 1/32W
RB838 9450360979 R-NETWORK 10KX4 1/32W
SC1001 9450763503 SURGE-ABSORBER
SC1002 9450763503 SURGE-ABSORBER
SC1021 9450763503 SURGE-ABSORBER
SC1022 9450763503 SURGE-ABSORBER
SC1023 9450763503 SURGE-ABSORBER
SC1024 9450763503 SURGE-ABSORBER
SC1025 9450763503 SURGE-ABSORBER
SC1026 9450763503 SURGE-ABSORBER
SC1027 9450763503 SURGE-ABSORBER
SC4001 9450763503 SURGE-ABSORBER
SC4002 9450763503 SURGE-ABSORBER
SC4003 9450763503 SURGE-ABSORBER
SC4004 9450763503 SURGE-ABSORBER
SC4005 9450763503 SURGE-ABSORBER
SW301 9450262792 SWITCH,PUSH 1P-1TX1
SW302 9450262792 SWITCH,PUSH 1P-1TX1
X1351 6520021754 OSC,CRYSTAL27.000000MHZ
X201 6520037595 OSC,CRYSTAL 25.000MHZ
X2301 6451039279 OSC,CRYSTAL 82.0MHZ
X8001 6520021754 OSC,CRYSTAL27.000000MHZ
X8801 9450837556 OSC,CRYSTAL 25.0MHZ
A1600 ASSY,PWB,SENSOR C KS4A
C1814 3034093426 CERAMIC 0.1U K 16V
IC1814 4106312708 IC MCP9801T-M/SN
R1825 3012261516 MT-GLAZE 0.000 ZA 1/16W
R1826 3012261516 MT-GLAZE 0.000 ZA 1/16W
A1800 ASSY,PWB,SENSOR A KS4A
C1691 3033645913 CERAMIC 0.22U K 16V
IC1692 4106312708 IC MCP9801T-M/SN
R1691 3012248814 MT-GLAZE 100 JA 1/16W
R1692 3012248814 MT-GLAZE 100 JA 1/16W
R1693 3012248814 MT-GLAZE 100 JA 1/16W
A8730 ASSY,PWB,FILTER SW KS4A
SW1891 9450635176 SWITCH,PUSH 2P-2TX3
AA600 ASSY,PWB,POWER KS4A
! C601 3040942002 MT-POLYEST 0.47U K 275V
! C602 4041282401 MT-POLYEST 0.22U M 275V
! C603 3040735109 CERAMIC 470P K 250V
! C604 3040735109 CERAMIC 470P K 250V
! C605 4041282401 MT-POLYEST 0.22U M 275V
