Chapter 1 Preparation — Using the remote control
ENGLISH - 31
Connecting to the projector with a cable
When controlling the projector by wired remote control, connect the <REMOTE 1 IN> terminal on the projector to the remote control wired
terminal on the remote control by a commercial M3 stereo mini jack cable.
The remote control is effective even in places where an obstacle stands in the light path or where devices are susceptible to outside light.
Connecting terminals
M3 stereo mini jack cable (commercially available)
Remote control
Connecting to the remote
control wired terminal
Attention
f Use a cable that is 15 m (49'3") or shorter, with dual core shielded. The remote control may not operate when the length of the cable
exceeds 15 m (49'3") or when the shielding of the cable is inadequate.
