Specifications
Power supply: 100 V – 240 V ~, 50 Hz/60 Hz
Power consumption: 180 W [During standby (when fan is
stopped): Approx. 5 W]
Amps: 2.2 A – 1.0 A
LCD panel:
Panel size (diagonal): 0.55 type (13.97 mm)
Aspect ratio: 4:3
Display method: 3 transparent LCD panels (RGB)
Drive method: Active matrix method
Pixels: 480 000 (800 x 600) x 3 panels
Lens: Manual zoom (1 - 1.2) / Manual focus
F 1.8 - 1.9, f 17.0 mm - 20.4 mm
Lamp: UHM lamp (130 W)
Luminosity: 1 400 lm
Scanning frequency (for RGB signals):
Horizontal scanning frequency: 15 kHz – 91 kHz
Vertical scanning frequency: 50 Hz – 85 Hz
Dot clock frequency: Less than 100 MHz
YPBPR signals: 525i (480i), 525p (480p), 625i (576i),
625p (576p), 750p (720p), 1 125i (1 080i)
Colour system: 7 (NTSC/NTSC 4.43/PAL/PAL-M/PAL-N/
PAL60/SECAM)
Projection size: 838.2 mm - 7 620 mm (33˝ - 300˝)
Throw distance: 1.2 m - 10.9 m (3´11˝ - 35´9˝)
Optical axis shift: 6:1 (fixed)
Screen aspect ratio: 4:3
Installation: Front/Rear/Ceiling/Desk (Menu selection
method)
Speaker: 2.8 cm round x 1
Max. useable volume output: 1 W (mono)
Connectors
RGB IN: Single-line, D-SUB HD 15-pin (female)
During YPBPR input:
Y: 1.0 V [p-p] (Including sync), 75 Ω
PB, PR : 0.7 V [p-p], 75 Ω
During RGB input:
R.G.B.: 0.7 V [p-p], 75 Ω
G.SYNC: 1.0 V [p-p], 75 Ω
HD/SYNC: TTL, automatic plus/minus polarity
compatible
VD: TTL, automatic plus/minus polarity
compatible
