Panasonic PT-LM2E - Appendix; List of Compatible Signals

58-ENGLISH
Appendix
*1 The “i” appearing after the resolution indicates an interlaced signal.
*2 The following symbols are used to indicate picture quality.
AA Maximum picture quality can be obtained.
A Signals are converted by the image processing circuit before picture
is projected.
B Some loss of data occurs to make projection easier.
*3 Signals with “OK” in the “RESIZING” column can be set using the
“RESIZING” command in the “POSITION” menu. (page 40)
*4 Signals that are compatible with the “FRAME LOCK” function. (page 40)
List of compatible signals
720 x 480i 15.734 59.940 A OK Video/S-Video
720 x 576i 15.625 50.000 A OK Video/S-Video
720 x 480i 15.734 59.940 13.500 A OK YPBPR/RGB
720 x 576i 15.625 50.000 13.500 A OK YPBPR/RGB
720 x 483 31.469 59.940 27.000 A OK YPBPR/RGB
720 x 576 31.250 50.000 27.000 A OK
YPBP
R/RGB
1 920 x 1 080i 33.750 60.000 74.250 A
YPBPR
/RGB
1 920 x 1 080i 28.125 50.000 74.250 A
YPBPR/RGB
1 280 x 720 45.000 60.000 74.250 A
YPBPR/RGB
640 x 400 31.469 70.086 25.175 A OK RGB
640 x 400 37.861 85.081 31.500 A OK RGB
640 x 480 31.469 59.940 25.175 A OK RGB
640 x 480 35.000 66.667 30.240 A OK RGB
640 x 480 37.861 72.809 31.500 A OK RGB
640 x 480 37.500 75.000 31.500 A OK RGB
640 x 480 43.269 85.008 36.000 A OK RGB
800 x 600 35.156 56.250 36.000 AA RGB
800 x 600 37.879 60.317 40.000 AA RGB
800 x 600 48.077 72.188 50.000 AA RGB
800 x 600 46.875 75.000 49.500 AA RGB
800 x 600 53.674 85.061 56.250 AA RGB
832 x 624 49.725 74.550 57.283 A RGB
1 024 x 768 48.363 60.004 65.000 A RGB
1 024 x 768 56.476 70.069 75.000 A RGB
1 024 x 768 60.023 75.029 78.750 A RGB
1 024 x 768 68.678 84.997 94.500 A RGB
1 024 x 768i 35.520 86.952 44.897 A RGB
1 152 x 864 63.995 71.184 94.200 A RGB
1 152 x 864 67.500 74.917 108.000 B RGB
1 152 x 864 76.705 85.038 121.500 B RGB
1 152 x 870 68.681 75.062 100.000 B RGB
1 280 x 960 60.000 60.000 108.000 B RGB
1 280 x 1 024 63.981 60.020 108.000 B RGB
1 280 x 1 024 79.977 75.025 135.001 B RGB
1 280 x 1 024 91.146 85.024 157.500 B RGB
1 400 x 1 050 63.981 60.020 108.000 B RGB
1 600 x 1 200 75.000 60.000 162.000 B RGB
Display
resolution
(dots)*
1
Scanning
frequency
H
(kHz)
V
(Hz)
Dot clock
frequency
(MHz)
quality*
2
RESIZING *
3
NTSC/NTSC4.43/
PAL-M/PAL60
PAL/PAL-N/SECAM
525i
625i
525p
625p
HDTV60
HDTV50
750p
VGA400
VGA480
SVGA
MAC16
XGA
MXGA
MAC21
MSXGA
SXGA
UXGA
Format Mode
*
4
*
4
*
4
*
4
*
4
*
4
*
4
