Panasonic PT-TW231RU

Technical Information
72
- ENGLISH
Appendix
Other terminals
Pin assignments and signal names of <S-VIDEO IN> terminal
J
Outside view
Pin No. Signal names
GND (luminance signal)
GND (color signal)
Luminance signal
Color signal
Pin assignments and signal names of <COMPUTER IN 1/COMPONENT
J
IN> terminal
Outside view
Pin No. Signal names
: Not assigned
- , , : GND terminals
R/P
R
G/G SYNC/Y
B/P
B
+ 5 V
DDC data
HD/SYNC
VD
DDC clock
Pin assignments and signal names of <COMPUTER IN 2/MONITOR OUT>
J
terminal
Outside view
Pin No. Signal names
, , , , : Not assigned
- , : GND terminals
R
G
B
HD/SYNC
VD
Pin assignments and signal names of <HDMI> terminal
J
Outside view
Pin No. Signal names Pin No. Signal names
T.M.D.S data 2+ T.M.D.S clock shield
T.M.D.S data 2 shield T.M.D.S clock
-
T.M.D.S data 2
-
CEC
T.M.D.S data 1+ —
T.M.D.S data 1 shield SCL
T.M.D.S data 1
-
SDA
T.M.D.S data 0+ DDC/CEC GND
T.M.D.S data 0 shield +5V
T.M.D.S data 0
-
Hot plug detection
T.M.D.S clock +
Odd-numbered pins to
Even-numbered pins to
