Panasonic R410A - Single Split Type S-140 PU1 R5;U-140 PE1 R8

1-14
1
Single-Type
1-1. Unit Specifi cations
Single Split Type S-140PU1R5 / U-140PE1R8
INDOOR MODEL S–140PU1R5
PANEL MODEL CZ-KPU2
OUTDOOR MODEL U–140PE1R8
Branch pipe MODEL –
PERFORMANCE TEST CONDITION AS/NZS3823.1
POWER SUPPLY
ø, Hz 1ø 50 Hz 3ø 50 Hz
V 230 V 240 V 400 V 415 V Min Max
C
O
O
L
I
N
G
CAPACITY
kW 14.0 14.0 3.3 15.5
BTU/h 47800 47800 11300 52900
CURRENT A 0.89 0.87 6.45 6.20 – –
INPUT POWER
W 115 115 4.195 k 4.195 k – –
TOTAL W – 4.310 k 4.310 k 840 6.000 k
ANNUAL CONSUMPTION TOTAL W *
4
– 2155 – – –
EER/AEER /STR RAT TOTAL (W/W) – –
3.25/3.22/– 3.25 3.93 2.58
Erp *
6
Pdsign kW ––––––
SEER (W/W) ––––––
Class ––––––
POWER FACTOR % – – 94 94 – –
NOISE INDOOR
(H/L)
dB–A 46/34
Power Level dB 64/51
NOISE OUTDOOR
(H/L)
dB–A 54/–
Power Level dB 71/–
H
E
A
T
I
N
G
CAPACITY
kW 16.0 16.0 4.1 18.0
BTU/h 54600 54600 14000 61400
CURRENT A 0.80 0.79 6.50 6.25 – –
INPUT POWER
W 105 105 4.225 k 4.225 k – –
TOTAL W – 4.330 k 4.330 k 900 5.900 k
COP/ACOP /STR RAT TOTAL (W/W) – –
3.70/3.66/– 3.70 4.56 3.05
Erp *
6
Pdsign kW ––––––
Tbivalen ˚C ––––––
SCOP (W/W) ––––––
Annual consumption kWh ––––––
Class ––––––
POWER FACTOR % – – 94 94 – –
NOISE INDOOR
(H/L)
dB–A 46/34 – / /
Power Level dB 64/51 –
NOISE OUTDOOR
(H/L)
dB–A – 55/– / /
Power Level dB – 71/–
EXTRA LOW TEMP TOTAL CAPACITY(kW)/INPUT POWER(W)/COP –
MAX CURRENT(A)/MAX INPUT POWER(W) 0.89/115 k 0.87/115 k 11.0/7.150 k 11.0/7.450 k /
STARTING CURRENT(A)/COMP OUTPUT(W) – –
6.50/3.0 K 6.25/3.0 K /
NETWORK IMPEDANCE(ΩMAX.) – –
FM OUTPUT (W) 90 90 × 2 /
MOISTURE REMOVAL VOLUME L/h(Pt/h) 6.0 (12.6) –
Extarnal static pressure
Pa (mmAq) –
I/D AIR
FLOW
COOL m
3
/min (ft
3
/min) 36 (1271)
HEAT m
3
/min (ft
3
/min) 36 (1271)
O/D AIR
FLOW
COOL m
3
/min (ft
3
/min) 135 (4767)
HEAT m
3
/min (ft
3
/min) 120 (4238)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40 k (119.9) /
P
R
O
D
I
M
HEIGHT
:
H mm (inch) 319 (12–9/16) 1416 (55–3/4) /
WIDTH
:
W mm (inch) 840 (33–3/32) 940 (37–1/32) /
DEPTH
:
D mm (inch) 840 (33–3/32) 340 (13–13/32) /
P
A
C
D
I
M
HEIGHT
:
H mm 361 1556 /
WIDTH
:
W mm 929 1055 /
DEPTH
:
D mm 929 485 /
MASS
(NET) kg(lb) 27 98 /
(GROSS) kg(lb) 34 108 /
LAYERS LIMIT (actually) 11(12) 1(2)
Operation
Condition
Cool (DBT) 18˚C – 32˚C -15˚C – 46˚C
Heat (DBT) 16˚C – 30˚C -20˚C – 24˚C
P
I
P
I
N
G
PIPE DIAMETER mm (inch)
(Liquid) ø 9.52(3/8) (Gas) ø 15.88(5/8) (Liquid) ø 9.52(3/8) (Gas) ø 15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0(16.4) fl ared type, 5.0(16.4)
PIPE LENGTH RANGE m (ft) 5 – 75 (16.4 – 246.1) – –
I/D&O/D HEIGHT DIRRERENCE m (ft) 15 (OD located lower)/30 (OD located higher) (49.2/98.4)
ADD GAS AMOUNT g/m (oz/ft) 50 (537.6)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)
*1
:
In case it is necessary to indicate the air fl ow volume in (l/s), the value in (m
3
/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2
:
If the EUROVENT Certifi ed models can be operated under the “extra-low” temperature condition, -7°C dry bulb and -8°C wet–bulb temperatures with rated voltage
230 V shall be used.
*3
:
Network Impedance shall be applicable for EUROPE and CHINA models.
*4
:
The annual consumption is calculated by multiplying the input power at 230 V (400 V) by an average of 500 hours per year in cooling mode.
*5
:
EER and COP classification is at 230 V (400 V) only in accordance with EU directive 2002/31/EC.
*6
:
SEER and SCOP classification is at 230V (400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season,
Other fiche data indicates in an attached sheet.
