20 Illustration of IC 痴, Transistors and Diodes 79
21 Terminal Function of IC 痴
80
21.1. IC701 (AN22004A-NF) Servo Amplifier
80
21.2. IC702 (MN6627934CH) Servo Processor/ Digital Signal
Processor/ Digital Filter/ D/A Converter
80
21.3. IC703 (AN8739SBTE2) Focus Coil/ Tracking Coil/
Traverse Motor/ Spindle Motor Driver
81
21.4. IC305 (C2CBJF000017) System Microprocessor
81
22 Troubleshooting Guide
83
23 Parts Location and Replacement Parts List
84
23.1. Deck Mechanism (RAA4502-S)
85
23.2. CD Loading Mechanism (RD-DAC026-S)
88
23.3. Cabinet
91
23.4. Electrical Parts List
94
23.5. Packing Materials & Accessories Parts List
102
23.6. Packaging
103
