10.1 Error detection for Cassette Mechanism
block
TOP PREVIOUS NEXT
TOP PREVIOUS NEXT
No.
Error ErrorDisplay Problem condition
1 MODE SWdetection error H01 Faulty operation of cassette mechanism.Faulty contact or short-circuit of mechanism mode switch (S951,
S971).
2 REC INH SWdetection
error
H02 Recording not possible.Faulty contact or short-circuit of REC INH switch (S974, S975).
3 HALF SWdetection error H03 Playback cannot perform.Faulty contact or short-circuit of HALF siwtch (S952, S972).
4 Reel Pulsedetection error F01 The tape advances slightly and then stops.Faulty reel pulse, faulty hole detect IC (IC951, IC971).
5 TPS abnormal F02 Cassette deck will not perform TPS function.Faulty playback EQ/recording amplifier IC (IC101).
