Panasonic SA-AK44 - Components Lists

Ref. No. Part No. Part Name & Description Remarks
50 XTB3+10J SCREW [M]
51 XTB3+10JFZ SCREW [M]
52 XTB3+20J SCREW [M]
53 XTBS26+10J SCREW [M]
54 XTBS3+8JFZ1 SCREW [M]
55 XTW3+15T SCREW [M]
56 XTW3+8T SCREW [M]
57 RGUX0376Z-S 3D AI BUTTON
58 RMCX0020 REGULATOR IC CLIP [M]
61 RGUX0380Z-S KARAOKE BUTTON
20.4. Component Parts List
Ref. No. Part No. Part Name & Description Remarks
PRINTED CIRCUITS BOARDS
REPX0192D CD SERVO P.C.B.
[M](RTL)
REPX0232B MAIN/TUNER P.C.B. [M](RTL)
REPX0254A PANEL P.C.B. [M](RTL)
REPX0254A HEADPHONE P.C.B. [M](RTL)
REPX0254A TACT SWITCH (1) P.C.B. [M](RTL)
REPX0254A TACT SWITCH (2) P.C.B. [M](RTL)
REPX0108 MECHANISM (DECK 1) P.C.B. [M](RTL)
REPX0108A MECHANISM (DECK 2) P.C.B. [M](RTL)
REP2578A-N CD LOADING P.C.B. [M](RTL)
REP2578A-N CD DETACT P.C.B. [M](RTL)
REP2578A-N SPINDLE POSITION P.C.B. [M](RTL)
REPX0198B DECK P.C.B. [M](RTL)
REPX0233C POWER P.C.B. [M](RTL)
REPX0234D AC TRANSFORMER P.C.B.
[M](RTL)(E/EG)
REPX0234C AC TRANSFORMER P.C.B.
[M](RTL)(EB)
REPX0234D SUB TRANSFORMER P.C.B.
[M](RTL)(E/EG)
REPX0234C SUB TRANSFORMER P.C.B.
[M](RTL)(EB)
INTEGRATED CIRCUITS
IC1 TA7291P IC DRIVE [M]
IC101 LA1833NMNTLM IC IF & MPX [M]
IC102 LC72131MDTRM IC PLL [M]
IC301 BH3874AKS2 IC ASP [M]
IC302 M5218AP IC BUFFER AMP [M]
IC304 BA4558FE2 IC DUAL OP-AMP [M]
IC305 TC4052BFNELM IC ANALOG SWICH [M]
IC500 RSN309W44B IC HIC
[M]
IC501 STK470-090 IC VOLTAGE REGULATOR
[M]
IC600 M38B79MFA158 IC MICRO-PROCESSOR [M]
IC601 BU2090AF-E2 IC I/O EXPANDER [M]
IC602 BU2090AF-E2 IC I/O EXPANDER [M]
IC701 AN8885SBE1 RFAMP [M]
IC702 MN662790RSC LSI [M]
IC703 AN8739SBE2 IC 4CH DRIVER [M]
IC951 0N2180RLC1 IC PHOTO INTERRUPTER [M]
