Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEX0129 14P FFC [M]
2 REEX0101 28P FFC [M]
3 REEX0127 20P FFC [M]
4 REEX0130 19P FFC [M]
5 RGB0113-N PANA BADGE (HOOK TYP [M]
6 RGKX0070-S CD LID [M]
7 RGKX0071A-SB CD ORNAMENT
8 RGLX0028-Q POWER LIGHTING CHIP [M]
9 RGLX0030-Q DISC LIGHT CHIP [M]
10 RGPX0038L-SL FRONT PANEL
11 RGRX0017D-AB REAR PANEL E
11 RGRX0017D-CB REAR PANEL EG
11 RGRX0017D-DB REAR PANEL EB
12 RGUX0368A-SB POWER BUTTON
13 RGUX0369Z-S CD EJECT BUTTON
14 RGUX0371-SB DISC BUTTON
15 RGUX0372A-SB DECK BUTTON
16 RGUX0378Z-S DECK EJECT BUTTON L
17 RGUX0379Z-S DECK EJECT BUTTON R
18 RGUX0397Z-S DISPLAY BUTTON
19 RGUX0400-SB AUXILIARY BUTTON
20 RGUX0410-Q S. WOOFER BUTTON [M]
21 RGUX0375-Q1 AMAZING BUTTON [M]
22 RGUX0367-QB FUNCTION BUTTON
23 RGWX0055-S VOLUME KNOB [M]
24 RHD30002-H SCREW [M]
25 RKA0059-K LEG RUBBER [M]
26 RKFX0083-SB CASS LID (L)
27 RKFX0084-SB CASS LID (R)
28 RKFX0085-KB CASS. HOLDER (L)
29 RKFX0086-KB CASS. HOLDER (R)
30 RKMX0057-S TOP CABINET (BENT) [M]
31 RKWX0148A-HB CASS. WIN (L)
32 RKWX0149A-HB CASS. WIN (R)
33 RKWX0156A FL FILTER [M]
34 RMBX0016-1 CASS. OPEN SPRING [M]
35 RMKX0053 BOTTOM CHASSIS
36 RMKX0044-B INNER CHASSIS
37 RMKX0045-B T-BRACKET
38 RMNX0039-HB SUB-TRANS SUPPORT
39 RMNX0038 FL HOLDER [M]
40 RSCX0020 SHILED PLATE [M]
41 RSCX0052 SHIELD PLATE HEAD [M]
42 RSCX0058 DECK SHIELD PLATE [M]
43 RUS757ZAA CASSETTE HALF SPRING [M]
44 RXGX0001 DAMPER GEAR [M]
45 RXXX0021 HEAT SINK UNIT [M]
46 RYQX0040A-SL CONTROL BUTTON UNIT
47 RYQX0037-S2 JOY JOG UNIT [M]
48 RYQX0045A-S FL ORNAMENT UNIT [M]
48-1 RKWX0155-H REMOTE SENSOR WINDOW [M]
49 SHE187-5 PCB SUPPORT (NO PIN) [M]
