Panasonic SA-HR45E - Page 67

Ref.
No.
Part No. Part Name & Description Remarks
VARIABLE RESISTORS
VR400 EVEKD2F3024B VOLUME [M]
SWITCHES
S401 EVQ21405RJ SW POWER [M]
S402 EVQ21405RJ SW < I/P SELECT [M]
S403 EVQ21405RJ SW I/P SELECT > [M]
S404 EVQ21405RJ SW ENTER [M]
S406 EVQ21405RJ SW -MENU/-SETUP/RETURN [M]
S407 EVQ21405RJ SW TUNE - [M]
S408 EVQ21405RJ SW TUNE + [M]
CONNECTORS
CN200A K1MN18A00046 18P CONNECTOR [M]
CN200B K1MN18A00046 18P CONNECTOR [M]
CN400 K1MP07A00002 7P CONNECTOR [M]
CN401 K1MP07A00002 7P CONNECTOR [M]
CN402 K1MP08A00003 8P CONNECTOR [M]
CN403A K1MN16AA0003 16P FFC CONNECTOR [M]
CN403B K1MN16AA0003 16P FFC CONNECTOR [M]
CN405 K1MP03A00012 3P CONNECTOR [M]
CN800A K1MP10A00007 10P CONNECTOR [M]
CN801 K1MP05A00009 5P CONNECTOR [M]
CN802A K1MP05A00009 5P CONNECTOR [M]
CN850 K1KA10AA0319 10P CONNECTOR [M]
CN904A K1MN18A00046 18P CONNECTOR [M]
CN904B K1MN18A00046 18P CONNECTOR [M]
CN906 K1MP04A00007 4P CONNECTOR [M]
CN5500 K1KA02AA0186 FAN CONNECTOR [M]
CP101 ENG07812QF TUNER PACK [M]
THERMISTOR
TH701 D4CAC8R00002 THERMISTOR [M]
COILS & TRANSFORMERS
L101 G0A200D00002 RF CHOKE COIL [M]
L140 J0JBC0000041 CHIP INDUCTOR [M]
L141 J0JBC0000041 CHIP INDUCTOR [M]
L401 J0JBC0000019 CHIP INDUCTOR [M]
L402 J0JBC0000019 CHIP INDUCTOR [M]
L403 J0JBC0000019 CHIP INDUCTOR [M]
L404 J0JBC0000019 CHIP INDUCTOR [M]
L405 J0JBC0000019 CHIP INDUCTOR [M]
L406 J0JBC0000019 CHIP INDUCTOR [M]
L500 ETQA15B220 CHOKE COIL [M]
L502 ETQA15B220 CHOKE COIL [M]
L503 ETQA15B220 CHOKE COIL [M]
L504 ETQA17B150 CHOKE COIL [M]
L505 ETQA17B150 CHOKE COIL [M]
L506 ETQA17B150 CHOKE COIL [M]
L507 ETQA17B150 CHOKE COIL [M]
L701 ELF18N067E COMMON MODE COIL [M]
L702 ELF21N015E COMMON MODE COIL [M]
L703 ELF21N015E COMMON MODE COIL [M]
L800 G0A200D00002 RF CHOKE COIL [M]
L801 G0A200D00002 RF CHOKE COIL [M]
L802 G0A200D00002 RF CHOKE COIL [M]
L803 G0A200D00002 RF CHOKE COIL [M]
L804 G0A200D00002 RF CHOKE COIL [M]
L805 G0A200D00002 RF CHOKE COIL [M]
L806 G0A200D00002 RF CHOKE COIL [M]
L850 G0A200D00002 RF CHOKE COIL [M]
L851 G0A200D00002 RF CHOKE COIL [M]
L852 G0A200D00002 RF CHOKE COIL [M]
L1001 G1C2R2K00012 CHIP INDUCTOR [M]
L1002 G1C2R2K00012 CHIP INDUCTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
L1003 G1C2R2K00012 CHIP INDUCTOR [M]
L1004 G1C2R2K00012 CHIP INDUCTOR [M]
L1101 G1C2R2K00012 CHIP INDUCTOR [M]
L1102 G1C2R2K00012 CHIP INDUCTOR [M]
L1103 G1C2R2K00012 CHIP INDUCTOR [M]
L1301 G0B600D00002 CHOKE COIL [M]
L1302 G1C1R0MA0061 CHIP INDUCTOR [M]
LB500 J0JKB0000020 EMI BEAD CORE [M]
LB501 J0JKB0000020 EMI BEAD CORE [M]
LB502 J0JKB0000020 EMI BEAD CORE [M]
LB503 J0JKB0000020 EMI BEAD CORE [M]
LB504 J0JKB0000020 EMI BEAD CORE [M]
LB505 J0JKB0000020 EMI BEAD CORE [M]
LB506 J0JKB0000020 EMI BEAD CORE [M]
LB507 J0JKB0000020 EMI BEAD CORE [M]
LB508 J0JKB0000020 EMI BEAD CORE [M]
LB509 J0JKB0000020 EMI BEAD CORE [M]
LB704 J0JKB0000020 EMI BEAD CORE [M]
LB800 J0JKB0000020 EMI BEAD CORE [M]
LB5400 J0JKB0000020 EMI BEAD CORE [M]
T701 ETS48AA196AC MAIN TRANSFORMER [M]
T721 ETS19AB1X6AG BACKUP TRANSFORMER [M]
T800 ETS28AU379AC SUB TRANSFORMER [M]
COMPONENT COMBINATIONS
Z400 B3RAD0000087 REMOTE SENSOR [M]
Z1101 J0JKB0000020 EMI BEAD CORE [M]
ZA701 EYF52BCY FUSE CLIP [M]
ZA702 EYF52BCY FUSE CLIP [M]
ZJ100 REX1161-1 WIRE [M]
ZJ101 REXV0071-2 GROUNDING WIRE [M]
ZJ502 K9ZZ00001279 EARTH PLATE [M]
ZJ701 K4CZ01000027 EARTH LUG [M]
PC701 B3PBA0000402 PHOTO COUPLER [M]
PC721 B3PBA0000402 PHOTO COUPLER [M]
SNE1 K9ZZ00001279 EARTH PLATE [M]
SNE2 K9ZZ00001279 EARTH PLATE [M]
SNE3 K9ZZ00001279 EARTH PLATE [M]
SNE4 K9ZZ00001279 EARTH PLATE [M]
CERAMIC FILTERS
CF301 H2A1005A0005 10MHZ RESONATOR [M]
RELAY
RY721 K6B1AEA00003 PC POWER RELAY [M]
OSCILLATORS
X140 H0H433400002 CRYSTAL 4.33MHZ [M]
X1001 H0J122200002 CYRSTAL [M]
X5400 H2A6023A0011 CERAMIC RESONATOR [M]
X5401 H2A7003A0011 CERAMIC RESONATOR [M]
DISPLAY TUBE
FL401 A2BB00000158 FL DISPLAY [M]
FUSES
F1 K5D402BLA013 FUSE T4AL 250V [M]
JACKS
P701 K2AA2B000015 AC INLET [M]
