Panasonic SA-HR45E - Page 68

Ref.
No.
Part No. Part Name & Description Remarks
JK101 K4BK04H00008 JK 4P AUD DVD/DVR OUT/IN [M]
JK102 K4BK04H00008 JK 4P AUD TV/AUX IN [M]
JK103 K2HA102B0086 JK 1P SWFR OUT [M]
JK503 K4AA04B00023 JK 4P SPK FRT [M]
JK504 K4AA06B00012 JK 6P SPK SUR/CTR [M]
JK1301 B3RAB0000048 JK OPTICAL TV [M]
JK1302 B3RAB0000048 JK OPTICAL DVD/DVR [M]
JK1303 K4BK01H00010 JK COAX INPUT [M]
HP401 K2HC103A0024 JK HP [M]
HP402 K2HC1YYA0005 JK MUSIC PORT [M]
JW400 RWJ1807100SQ 7P WIRE (VOL-MN) [M]
JW401 RWJ1815130SQ 15P WIRE (PAN-MAIN) [M]
JW405 RWJ1803220SQ 3P WIRE (MN-DSP) [M]
JW700 REEV0122 RED WIRE (AC-PWR) [M]
JW701 REEV0123 WHITE WIRE (AC-PWR) [M]
JW800 RWJ1810100SQ 10P WIRE (PWR-MN) [M]
JW801 RWJ1805110SQ 5P WIRE (PANEL-PWR) [M]
JW802 RWJ1805110SQ 5P WIRE (PWR-MN) [M]
JW850 REXV0069 10P WIRE (PWR-DAMP) [M]
JW906 RWJ1804110SQ 4P WIRE (MAIN DSP) [M]
PACKING MATERIALS
P1 RPGV0458 PACKING CASE [M]EG-
K, E,-K
P1 RPGV0456 PACKING CASE [M]EG-
S, E-S
P2 RPNV0093-2 POLYFOAM [M]
P3 VPF1122-1 POLYBAG [M]
ACCESSORIES
A1 N2QAYB000010 REMOTE CONTROL [M]
A1-1 RKK-HTR0051K R/C BATTERY COVER [M]
A2 K2CQ2CA00007 AC CORD [M]
A3 RQTV0248-D O/I BOOK (Ge/It/Fr) [M]EG
A3 RQTV0249-H O/I BOOK (Sp/Du/Da/Sw) [M]EG
A3 RQTV0252-E O/I BOOK (En/Po/Cz) [M]E
A4 RSA0007-L1 FM ANTENNA WIRE [M]
A5 N1DAAAA00002 AM LOOP ANTENNA [M]
A6 RQCA1029 SP LABEL SHEET [M]
RESISTORS
R101 ERJ3GEYJ102V 1K 1/16W [M]
R102 ERJ3GEYJ102V 1K 1/16W [M]
R103 ERJ3GEYJ102V 1K 1/16W [M]
R104 ERJ3GEYJ102V 1K 1/16W [M]
R105 ERJ3GEYJ102V 1K 1/16W [M]
R106 ERJ3GEYJ102V 1K 1/16W [M]
R107 ERJ3GEYJ102V 1K 1/16W [M]
R108 ERJ3GEYJ102V 1K 1/16W [M]
R110 ERJ3GEYJ102V 1K 1/16W [M]
R131 D0GB473JA007 47K 1/16W [M]
R132 D0GB473JA007 47K 1/16W [M]
R133 ERJ3GEYJ102V 1K 1/16W [M]
R134 ERJ3GEYJ102V 1K 1/16W [M]
R140 ERJ3GEYJ102V 1K 1/16W [M]
R141 D0GB104JA007 100K 1/16W [M]
R142 D0GB104JA007 100K 1/16W [M]
R143 ERJ3GEYJ102V 1K 1/16W [M]
R144 ERJ3GEYJ102V 1K 1/16W [M]
R151 ERJ3GEYJ103V 10K 1/16W [M]
R152 ERJ3GEYJ103V 10K 1/16W [M]
R153 ERJ3GEYJ103V 10K 1/16W [M]
R154 ERJ3GEYJ103V 10K 1/16W [M]
R201 D0GB332JA007 3.3K 1/16W [M]
R202 D0GB332JA007 3.3K 1/16W [M]
R203 D0GB683JA007 68K 1/16W [M]
R204 D0GB683JA007 68K 1/16W [M]
R205 D0GB151JA007 150 1/16W [M]
Ref.
No.
Part No. Part Name & Description Remarks
R206 D0GB151JA007 150 1/16W [M]
R207 D0GB151JA007 150 1/16W [M]
R208 D0GB151JA007 150 1/16W [M]
R209 D0GB560JA007 56 1/16W [M]
R210 D0GB560JA007 56 1/16W [M]
R211 D0GB560JA007 56 1/16W [M]
R212 D0GB560JA007 56 1/16W [M]
R213 ERJ3GEYJ102V 1K 1/16W [M]
R214 ERJ3GEYJ102V 1K 1/16W [M]
R221 D0GB123JA007 12K 1/16W [M]
R222 D0GB123JA007 12K 1/16W [M]
R223 D0GB182JA007 1.8K 1/16W [M]
R224 D0GB182JA007 1.8K 1/16W [M]
R225 D0GB123JA007 12K 1/16W [M]
R226 D0GB123JA007 12K 1/16W [M]
R227 D0GB153JA007 15K 1/16W [M]
R228 D0GB153JA007 15K 1/16W [M]
R229 D0GB123JA007 12K 1/16W [M]
R230 ERJ3GEYJ153V 15K 1/16W [M]
R235 D0GB392JA007 3.9K 1/16W [M]
R236 ERJ3GEYJ102V 1K 1/16W [M]
R237 D0GB332JA007 3.3K 1/16W [M]
R239 ERJ3GEYJ102V 1K 1/16W [M]
R240 D0GBR00JA008 0 1/16W [M]
R241 D0GBR00JA008 0 1/16W [M]
R242 ERJ3GEYJ102V 1K 1/16W [M]
R243 D0GB474JA041 470K 1/16W [M]
R244 ERJ3GEYJ822V 8.2K 1/16W [M]
R245 ERJ3GEYJ102V 1K 1/16W [M]
R247 ERJ3GEYJ102V 1K 1/16W [M]
R248 ERJ3GEYJ822V 8.2K 1/16W [M]
R249 D0GB474JA041 470K 1/16W [M]
R254 D0GB473JA007 47K 1/16W [M]
R255 D0GB473JA007 47K 1/16W [M]
R256 D0GB104JA007 100K 1/16W [M]
R257 D0GB104JA007 100K 1/16W [M]
R258 ERJ3GEYJ102V 1K 1/16W [M]
R259 ERJ3GEYJ102V 1K 1/16W [M]
R260 D0GB223JA007 22K 1/16W [M]
R261 D0GB223JA007 22K 1/16W [M]
R263 D0GB473JA007 47K 1/16W [M]
R264 D0GB473JA007 47K 1/16W [M]
R265 D0GB223JA007 22K 1/16W [M]
R266 D0GB223JA007 22K 1/16W [M]
R267 D0GB223JA007 22K 1/16W [M]
R268 D0GB473JA007 47K 1/16W [M]
R270 ERJ3GEYJ102V 1K 1/16W [M]
R272 ERJ3GEYJ102V 1K 1/16W [M]
R273 ERJ3GEYJ102V 1K 1/16W [M]
R275 ERJ3GEYJ103V 10K 1/16W [M]
R276 ERJ3GEYJ103V 10K 1/16W [M]
R277 D0GB223JA007 22K 1/16W [M]
R278 ERJ3GEYJ102V 1K 1/16W [M]
R279 ERJ3GEYJ102V 1K 1/16W [M]
R280 D0GB153JA007 15K 1/16W [M]
R281 D0GB393JA007 39K 1/16W [M]
R282 D0GB332JA007 3.3K 1/16W [M]
R283 D0GB332JA007 3.3K 1/16W [M]
R284 D0GB473JA007 47K 1/16W [M]
R285 D0GB473JA007 47K 1/16W [M]
R286 ERJ3GEYJ822V 8.2K 1/16W [M]
R287 D0GB474JA041 470K 1/16W [M]
R289 ERJ3GEYJ102V 1K 1/16W [M]
R290 ERJ3GEYJ102V 1K 1/16W [M]
R291 ERJ3GEYJ102V 1K 1/16W [M]
R292 ERJ3GEYJ102V 1K 1/16W [M]
R293 ERJ3GEYJ102V 1K 1/16W [M]
R294 ERJ3GEYJ102V 1K 1/16W [M]
R295 D0GBR00JA008 0 1/16W [M]
R296 D0GBR00JA008 0 1/16W [M]
R297 ERJ3GEYJ102V 1K 1/16W [M]
R298 ERJ3GEYJ102V 1K 1/16W [M]
R299 D0GB152JA007 1.5K 1/16W [M]
