Panasonic SA-PM08 - Power Supply Regulator and Control Circuits; Regulator, Control, and Relay Circuits

IC802
SI8050JLF118
REGULATOR
IC803
BA05T
REGULATOR
O G I
INOUT GND
C832
0.01
C828
6.3V220
C827
10V100
C825
0.01
Q806
KRC102MTA
POWER SUPPLY
CONT.
Q804
KRC102MTA
POWER SUPPLY
CONT.
C845
0.01
D841
RVD1SS133TA
D828
RVD1SS133TA
R862
100
C809
16V100
R861
100K
R816
470
Q805
2SB1566E
REGULATOR
Q815
2SD2144STA
STABILIZER
L803
100
H
D836
EK14LFH2K
R819
1K
R818
330
C826
10V680
R858
1K
C862
25V1000
L802
C824
3300
D833
RL1N4003N02
C823
0.1
D808
RL1N4003N02
R814
680
L804
D829
MTZJ9R1ATA
L805
D838
RL1N4003N02
R866
1.5
Q822
KRC102MTA
SWITCHING
(DC DET.)
R803
22K
R807
10K
C860
25V4.7
C802 0.01
C801
1000
D801
RL1N4003N02
AC IN
JK801
L801
Z801
F1
T2
BA
SCHEMATIC DIAGRAM - 23
C835
6.3V100
R820
1
C829
10V100
C831
0.01
D837
RL1N4003N02
D852
RL1N4003N02
1 2 3 4 5
VIN
SW OUT
GND
VOS
ON/ OFF
D835
RL1N4003N02
D832
RL1N4003N02
D834
RL1N4003N02
R811
RSFMB50KT-L
R859
100
T0.8A
T1A [GK]
[GCS]
230-240V 50/60Hz
[GCS]
220V 50Hz [GK]
:POSITIVE VOLTAGE LINE
AC4.5V
0V
2.8V
9V 12.6V
12V
5V 6.2V
8.6V
8.1V
12V
8.6V
0V
0V
1.9V
1.9V
4.8V 6.2V
13.1V
