SIGNAL GENERATOR OR
SWEEP GENERATOR
RADIO DIAL
SETTING
INDICATOR
(ELECTRONIC
VOLTMETER
OSCILLOSCOPE)
ADJUSTMENT(Shown
in Fig.1)
REMARKS
CONNECTIONS
FREQUENCY
Fashion a
loop of
several turns
of wire and
radiate signal
into loop of
receiver.
520 kHz Tuning capacitor
fully closed.
Headphone Jack (32
) Fabricate the
plug as shown in
Fig. 2 and then
connect the lead
wires of the plug to
the measuring
instrument.
Z101 (AM OSC Coil)
Adjust
maximum
output.
Fashion a
loop of
several turns
of wire and
radiate signal
into loop of
receiver.
600 kHz Tuning capacitor
fully open.
Headphone Jack (32
) Fabricate the
plug as shown in
Fig. 2 and then
connect the lead
wires of the plug to
the measuring
instrument.
Z101 (AM ANT Coil)
Adjust
maximum
output.
