Panasonic SA-PMX152EG - Check Point; Power PCB (SMPS PCB)

23
10. Check Point
10.1. Power PCB (SMPS PCB)
1
1
2
2
3
3
Sec.Cap.C5811
(>7.5Vor13.5V)
6
6
10.2 Main PCB
Fuse(F1)
(0ohm)
Pri.Cap(C5720)
(300Vormore)
4
4
IC1103
(3.3V)
Sec.Cap.C2905
(14.5/12V)
9
LB1101=5.2V
(IC1101)
10
LB1103=5.6V
(IC1102)
11
LB1108=5V
(IC1104)
5
LB1105=3.3V
(IC1115)
7
IC1111(12V)
8
D1115=32V
(IC1112)
12
LB1109=3.3V
(IC1105)
