Note:
When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again.
1.4. Safety Parts Information
Safety Parts List:
There are special components used in this equipment which are important for safety.
These parts are marked by in the Schematic Diagrams & Replacement Parts List. It is essential that these critical parts
should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the original design
without permission of manufacturer.
Safety Ref. No. Part No. Part Name & Description Remarks
23 RGRX0071A-A1 REAR PANEL UNIT
37 RKMX0141-1K3 TOP CABINET
65 REXX0728 BLACK WIRE (SMPS-AC)
66 REXX0730 RED WIRE (SMPS-AC)
401 RD-DDTX001-V TRAVERSE ASS’Y (RTL)
A2 K2CQ2CA00007 AC CORD EF/EG-K
A2 K2CZ3YY00005 AC CORD EB-K
PCB5 REPX0689G D-AMP P.C.B (RTL)
PCB6 REPX0728B SMPS P.C.B (RTL)
PCB7 REPX0728B AC INLET P.C.B (RTL)
DZ5701 ERZV10V511CS DIODE
L5701 ELF15N035AN LINE FILTER
L5702 ELF21N015A LINE FILTER
L5703 ELF21N015A LINE FILTER
T2900 G4D1A0000117 SWITCHING TRANSFORMER
T5701 ETS42BN1A6AD SWITCHING TRANSFORMER
T5751 ETS19AB2A6AG SWITCHING TRANSFORMER
PC5702 B3PBA0000402 PHOTO COUPLER
PC5720 B3PBA0000402 PHOTO COUPLER
PC5799 B3PBA0000402 PHOTO COUPLER
RY5701 K6B1AEA00003 RELAY
F1 K5D402BK0007 FUSE
F2 K5G162B00016 FUSE
FP2901 K5H1022A0011 IC PROTECTOR
FP2902 K5H2022A0011 IC PROTECTOR
TH5702 D4CAA5R10001 POWER THERMISTOR
P5701 K2AA2B000017 JK AC INLET
C5700 F1BAF1020020 1000pF
C5701 ECQU2A104MLC 0.1uF
C5702 ECQU2A104MLC 0.1uF
C5703 ECQU2A104MLC 0.1uF
C5704 F1BAF1020020 1000pF
C5705 F1BAF1020020 1000pF
