11.2.5. Waveform Table 5 (IC8001 ~ IC8422)
WF No. IC8001-151 (PLAY)
6Vp-p(2usec/div)
WF No. IC8421-3,9,10,11 (PLAY)
4.8Vp-p(2usec/div)
WF No. IC8001-152 (PLAY)
6.4Vp-p(500nsec/div)
WF No. IC8421-17 (PLAY)
WF No. IC8421-18,19,20,21,
22 (PLAY)
0.092Vp-p(2msec/div)
WF No. IC8421-24 (PLAY)
2.3Vp-p(500usec/div)
WF No. IC8421-25 (PLAY)
0.24Vp-p(500usec/div)
WF No. IC8422-1 (PLAY)
1.5Vp-p(500usec/div)
WF No. IC8422-2 (PLAY)
0.15Vp-p(500usec/div)
WF No. IC8422-9 (PLAY)
7.6Vp-p(2usec/div)
0.76Vp-p(500usec/div)
