Panasonic SB-FS730 - Page 76

DVDT-S20 TRACK 9
Y LEVEL 1.0 + 0.1Vp-p
DVDT-S20 TRACK 9
CYAN LEVEL 0.621 + 0.062Vp-p
DVDT-S20 TRACK 9
Y LEVEL 1.0 + 0.1Vp-p
DVDT-S20 TRACK 9
C
B LEVEL 0.525 + 0.053Vp-p
DVDT-S20 TRACK 9
CR LEVEL 0.525 + 0.053Vp-p
DVDT-S20 TRACK 9
Y + sync LEVEL 1.0 + 0.1Vp-p
Y TERMINATED WITH 75 Ohm TERMINATION
DVDT-S20 TRACK 9
Y LEVEL 1.0 + 0.1Vp-p
C TERMINATED WITH 75 Ohm TERMINATION
DVDT-S20 TRACK 9, Y+SYNC LEVEL 1.00+0.1Vp-p,
C LEVEL 0.621 + 0.062Vp-p.
LINE TERMINATED WITH 75 Ohm TERMINATION
DVDT-S20 TRACK 9, MAGENTA 0.842 + 0.04 Vp-p,
MAGENTA PHASE 61 + 4 Deg.
C
B 525 + 53 mVp-p, CR 525 + 53 mVp-p
RGB TERMINATED WITH 75 Ohm TERMINATION
DVDT-S20 TRACK 9, MAGENTA 0.842 + 0.04 Vp-p,
MAGENTA PHASE 61 + 4 Deg.Y LEVEL 1.0 + 0.1Vp-p
RGB TERMINATED WITH 75 Ohm TERMINATION
