Fig. 9-1.
10. Schematic Diagram Notes
- This schematic diagram may be modified at any time with the
development of new technology.
Notes:
S901:
Standby/on switch ( )
S902:
Source select switch (SELECT)
VR901:
Volume control VR (VOLUME)
- Indicated voltage values are the standard values for the unit
measured by the DC electronic circuit tester (high-impedance)
with the chassis taken as standard. Therefore, there may exist
some errors in the voltage values, depending on theinternal
impedance of the DC circuit tester.
No mark
: Power ON (FM or AM)
- Important safety notice:
Components identified by mark have special characteristics
important for safety.
Furthermore, special parts which have purposes of fire-retardant
(resistors), high-quality sound (capacitors), low-noise (resistors),
etc. are used.
When replacing any of components, be sure to use only
16
