Pin
No.
Terminal
Name
I/O Function
49 /DSP
MILP
O Latch signal output for IC401
50
DSP /
MIACK
I Acknowledge signal input from
IC401
51
DSP /
ODATA
I Zero detect signal input for
IC401
52 NC - Not used, open
53 NC - Not used, open
54 DSP
PLON
O Clock select signal output for
IC401
55 TU SD I FM/AM station detect signal
input
56 TU CE O Chip enable signal output for
tuner
57 TU DO O Data signal output for tuner
58 TU DIN/
ST
I Data signal input from tuner/FM
stereo signal input
59 TU CK O Clock signal output for tuner
60 RDS
RDDA
I Data signal input for IC601
61
RDS /
RDCL
O Clock signal output for IC601
62
V
CC
I Power supply terminal
63 RDS IDR I Ready signal input from IC601
64
V
SS
- GND
65 TUNER - Not used, open
66 DIGITAL O When digital input: “H” output
67
ANALOG
O When analog input: “H” output
68 JOG A I Volume control signal input
69 JOG B I Volume control signal input
70 LED
STBY
O LED (STANDBY) drive signal
output
71 /LED
STBY
O LED (STANDBY) drive signal
output (reverse)
72 NC - Not used, open
73
LED /
DIGITAL
O LED (DIGITAL INPUT) drive
signal output
74 NC - Not used, open
75 POWER O Power control signal output
76 NC - Not used, open
77 NC - Not used, open
78 OPT1 O OPT1 select signal output
79 OPT2 O OPT2 select signal output
80 NC - Not used, open
