(EG): SA-DT310EG
- The marking [RTL] indicates the retention time is limited for this
item. After the discontinuation of this assembly in production, it
will no longer be available.
- All parts are supplied by SPC.
Ref. No. Part No. Part Name & Description Pcs Remarks
1 REM0104 FAN UNIT(RAL801) 1
3 RHD30070 SCREW 1
4 RKA0150-K LEG 1
5 RKA0155-K LEG FELT 6
6 RKS0379-H BOTTOM COVER 1
7 RMA1643 FAN ANGLE 1
8 RMZ0676 BARRIER 1
9 RMZ0690 TOP BARRIER 1
10 XTB3+8J SCREW 5
11 XTBS3+8JFZ1 SCREW 9
12 XTW3+15T SCREW 2
13 J0KA00000047 FILTER 3
14 J0KD00000067 FILTER 1
15 RHD30092 SCREW 3
16 RMG0621-H RUBBER SHEET 2
17 RSC0680 DAMP SHIELD 1
18 RSC0686 SHIELD PLATE 1 1
19 RSC0704 SHIELD PLATE 2 1
20 REZ1532-1 FFC 1
21 RGK1629-S VOLUME ORNAMENT 1
22 RGL0622-Q LENS 1
23 RGU2192-S BUTTON,POWER 1
24 RGW0399-S KNOB,VOLUME 1
25 RHN90001 NUT 1
26 RSC0675 EARTH PLATE 1
27 XTBS26+8J SCREW 2
28 RGM0172-H NET 1
29 XTB3+6J SCREW 2
30 XTBS3+10JFZ1 SCREW 2
32 RSC0679 TOP SHIELD COVER 1
33 RYQ0460-S SIDE ORNAMENT1 / ASS'Y 1
34 RYQ0461-S SIDE ORNAMENT2 / ASS'Y 1
35 RYP1212-S FRONT PANEL ASS'Y 1
35-1 RKW0723-K SENSOR WINDOW 1
36 XTB3+12FFZ SCREW 2
38 RMZ0702 AMP BARRIER 1
39 RMN0195-1 FL PIECE 2
40 RMN0697 FL HOLDER 1
41 RSC0708 SHIELD PLATE 3 1
42 RSC0709 SHIELD PLATE 4 1
43 RSC0710 SHIELD PLATE 5 1
44 RKM0486-S TOP COVER 1
45 REX1166 WIRE ASS'Y / (W201/20P) 1
