Panasonic SB-W340E - Assembling and Disassembling

System : SC-
HT340GCSS
Music Center System : / SA-
HT340GCSS
Front Speaker : SB-FS340E-S
Surround Speaker : SB-FS341E-S
Center Speaker : SB-PC340E-S
Subwoofer : SB-W340E-S
System : SC-
HT340GCTS
Music Center System : / SA-
HT340GCTS
Front Speaker : SB-FS340E-S
Surround Speaker : SB-FS341E-S
Center Speaker : SB-PC340E-S
Subwoofer : SB-W340E-S
System : SC-HT340GS-
S
Music Center System : / SA-
HT340GS-S
Front Speaker : SB-FS340E-S
Surround Speaker : SB-FS341E-S
Center Speaker : SB-PC340E-S
Subwoofer : SB-W340E-S
SB-HT340E-S consists of SB-FS340E-S(X2), SB-FS341E-S(X2),
SB-PC340E-S(X1) & SB-W340E-S(X1)
2006 Matsushita Electric Industrial Co. Ltd.. All rights reserved.
Unauthorized copying and distribution is a violation of law.
1. Assembling and Disassembling
“ATTENTION SERVICER”
Some chassis components may have sharp edges. Be careful when disassembling and
servicing.
1. This section describes procedures for checking the operation of
the major printed circuit boards and replacing the main
3
