11
Getting started
VQT4Q15
1 AC IN terminal (> 19)
2 Speaker terminals (> 15)
3 Cooling fan
4 LAN port (> 18)
5 [BTT880] [BTT480] [BTT460] [BTT400]
USB port (> 18, 32)
6 HDMI AV OUT (ARC) terminal (> 16, 17)
7 [BTT880]
HDMI1 IN (CABLE/SAT) terminal (> 17)
8 [BTT880]
HDMI2 IN terminal (> 17)
9 DIGITAL AUDIO IN terminal (> 16, 17)
10 FM radio antenna terminal (> 16)
11 AUX terminal (> 16)
12 [BTT880]
Digital transmitter dock for wireless system
Main unit (Rear)
1 2 3 4 5 6 7 12118 9 10
1 2 3 4 5 6 119 10
[BTT880]
e.g., [BTT480] [BTT460] [BTT400]
SC-BTT880&480&460&400&300GNGSGA-VQT4Q15_mst.book 11 ページ ２０１２年１２月４日 火曜日 午後３時５０分
