Panasonic SC-HC29 User Manual

6
RQT9874
Overview of controls
Do the procedures with the remote control. You can also use the buttons on the main unit if they are the same.
A Standby/on switch [`], [1]
Press to switch the unit from on to standby mode or
vice versa. In standby mode, the unit is still
consuming a small amount of power.
B Select the audio source
On the remote control:
Press the corresponding button to select the source.
On the main unit:
C Basic playback control
D View the setup menu
E View the content information
F Select or confirm the option
G Open or close the sliding door
H Decrease the brightness of the display panel
To cancel, press the button again.
I Adjust the volume level
J Mute the sound
To cancel, press the button again.
“MUTE” is also cancelled when you adjust the volume
or when you switch off the system.
K View the play menu
L Select the sound effects
M SC-HC29
AUX IN terminal
N USB port ( )
SC-HC29
DC OUT terminal (Z“Charging a portable device”)
O SC-HC29
Select “BLUETOOTH” as the audio source
To start Bluetooth
®
pairing, press and hold the button.
SC-HC19
Select the dynamic bass effect
P SC-HC29
NFC touch area
Q Sliding door
R Display panel
S Remote control sensor
Distance: Within approximately 7 m
Angle: Approximately 20° up and down, 30° left and
right
Top view
SC-HC29.19 EB.EC RQT9874-1R EN.fm Page 6 Friday, April 18, 2014 9:46 AM

Panasonic SC-HC29 Specifications

General

Type	Home audio micro system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Karaoke	-
Impedance	8 Ω
Speaker type	1-way
RMS rated power	20 W
Number of speakers	2
Mid-range driver diameter	80 mm
Tuner type	Analog
Supported radio bands	FM
Preset stations quantity	30
Headphone connectivity	3.5 mm
Disc types supported	CD, CD-R, CD-RW
Audio formats supported	MP3
Power source	AC
Input voltage	110-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	22 W

Weight and Dimensions

Depth	107 mm
Width	400 mm
Height	197 mm
Weight	1900 g
