Specifications

1 Specifications are subject to change without notice.
2 Weight and dimensions are approximate.
3 Total harmonic distortion is measured by a digital spectrum
analyzer.
4 Total harmonic distortion is measured by using AES17 filter.
AMPLIFIER SECTION
RMS output power
10 % total harmonic distortion
Subwoofer ch
120 W per channel (100 Hz, 3 ≠ )
Front ch (L, R ch)
60 W per channel (1 kHz, 6 ≠)
Total RMS Dolby Digital mode power 240 W
FTC output power
1.0 % total harmonic distortion
Subwoofer ch
50 Hz to 110 Hz 40 W (3 ≠)
Front ch (L, R ch)
110Hzto20kHz25W(6≠)
Total FTC Dolby Digital mode power 90 W
TERMINAL SECTION
HDMI
This unit supports “HDAVI Control 5” function.
HDMI AV input (HDMI 1, HDMI 2) 2
Input connector Type A (19 pin)
HDMI AV output (To TV (ARC)) 1
Output connector Type A (19 pin)
Digital audio input
Optical (TV) 1
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only Optical (TV) input, LPCM)
Audio format LPCM, Dolby Digital, DTS
Speaker output
(Front L, R) 2
SUBWOOFER SECTION
1 way, 1 speaker system (Bass reflex type)
Woofer 16 cm (6-
1
/2q) cone typek1
MAIN UNIT GENERAL
Power consumption 40 W
In standby condition 0.05 W
Power supply AC 120 V, 60 Hz
Dimensions (WkHkD)
180 mmk408 mmk305 mm
(7-
3
/32qk16-
1
/16qk12-
1
/64q)
Mass (Weight)
5.6 kg (12.3 lbs)
Operating temperature range
0
o
C to 40
o
C (32
o
F to 104
o
F)
Operating humidity range
20 % to 80 % RH (no condensation)
FRONT SPEAKER
SECTION
2 way, 2 speaker system (Bass reflex type)
Woofer
3.5 cm (1-
3
/8q)k10 cm (4q)conetypek1
Tweeter 2.5 cm (1q) semi dome typek1
SPEAKER GENERAL
Horizontal Placement using the Stands
Dimensions (WkHkD)
800 mmk89 mmk75 mm
(31-
1
/2qk3-
1
/2qk2-
61
/64q)
Mass (Weight)
1.4 kg (3.1 lbs)
Horizontal Placement using the Speaker Feet
Dimensions (WkHkD)
800 mmk51 mmk58 mm
(31-
1
/2qk2-
1
/64qk2-
9
/32q)
Mass (Weight)
1.36 kg (3.0 lbs)
Horizontal Placement (for wall mount)
Dimensions (WkHkD)
800 mmkApprox. 49 mmk58 mm
(31-
1
/2qk1-
59
/64qk2-
9
/32q)
Mass (Weight)
1.36 kg (3.0 lbs)
Vertical Placement using the Base Stands
Dimensions (WkHkD)
135 mmk398 mmk135 mm
(5-
5
/16qk15-
43
/64qk5-
5
/16q)
Mass (Weight)
0.64 kg (1.4 lbs)
Vertical Placement (for wall mount)
Dimensions (WkHkD)
Approx. 49 mmk380 mmk58 mm
(1-
59
/64qk14-
61
/64qk2-
9
/32q)
Mass (Weight)
0.59 kg (1.3 lbs)
