Panasonic SC-HTB20

Reference
29
VQT4D53
Specifications

1 Specifications are subject to change without notice.
2 Weight and dimensions are approximate.
3 Total harmonic distortion is measured by a digital spectrum
analyzer.
4 Total harmonic distortion is measured by using AES17 filter.
AMPLIFIER SECTION
RMS output power
10 % total harmonic distortion
Subwoofer ch
110 W per channel (100 Hz, 3 ≠ )
Front ch (L, R ch)
65 W per channel (1 kHz, 6 ≠)
Total RMS Dolby Digital mode power 240 W
FTC output power
1.0 % total harmonic distortion
Subwoofer ch
50Hzto110Hz40W(3≠)
Front ch (L, R ch)
110Hzto20kHz25W(6≠)
Total FTC Dolby Digital mode power 90 W
TERMINAL SECTION
HDMI
This unit supports “HDAVI Control 5” function.
HDMI AV input (BD/DVD) 1
Input connector Type A (19 pin)
HDMI AV output (To TV (ARC)) 1
Output connector Type A (19 pin)
Digital audio input
Optical (TV, AUX) 2
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
Audio format
LPCM, Dolby Digital, DTS Digital Surround
Speaker output
(Front L, R) 2
SUBWOOFER SECTION
1 way, 1 speaker system (Bass reflex type)
Woofer 16 cm (6-
1
/2q) cone typek1
MAIN UNIT GENERAL
Power consumption 40 W
In standby condition Approx. 0.07 W
(When the other connected devices are turned off)
Power supply AC 120 V, 60 Hz
Dimensions (WkHkD)
180 mmk408 mmk305 mm
(7-
3
/32qk16-
1
/16qk12-
1
/64q)
Mass (Weight)
5.5 kg (12.2 lbs)
Operating temperature range
0
o
C to 40
o
C (32
o
F to 104
o
F)
Operating humidity range
20 % to 80 % RH (no condensation)
FRONT SPEAKER SECTION
1 way, 1 speaker system (Bass reflex type)
Full range
3.5 cm (1-
3
/8q)k10 cm (4q) cone typek1
SPEAKER GENERAL
Horizontal Placement using the Stands
Dimensions (WkHkD)
755 mmk91 mmk75 mm
(29-
47
/64qk3-
19
/32qk2-
61
/64q)
Mass (Weight)
1.3 kg (2.9 lbs)
Horizontal Placement using the Speaker Feet
Dimensions (WkHkD)
755 mmk52 mmk58.5 mm
(29-
47
/64qk2-
3
/64qk2-
5
/16q)
Mass (Weight)
1.3 kg (2.9 lbs)
Horizontal Placement (for wall mount)
Dimensions (WkHkD)
755 mmkApprox. 49 mmk58.5 mm
(29-
47
/64qk1-
59
/64qk2-
5
/16q)
Mass (Weight)
1.3 kg (2.9 lbs)
Vertical Placement using the Speaker bases
Dimensions (WkHkD)
126 mmk430 mmk130 mm
(4-
31
/32qk16-
15
/16qk5-
1
/8q)
Mass (Weight)
0.7 kg (1.6 lbs)
Vertical Placement (for wall mount)
Dimensions (WkHkD)
Approx. 49 mmk377.5 mmk58.5 mm
(1-
59
/64qk14-
55
/64qk2-
5
/16q)
Mass (Weight)
0.6 kg (1.4 lbs)
