24
VOLTAGE DATA (measurement status:Power On and No any external signal input )
1 PIN NO. VALUE
1 14.3V
2 14.3V
3 14.3V
4 14.3V
5 PIN NO. VALUE
1 5.2V
2 5.2V
3 NC
4 NC
5 NC
6 NC
7 3.3V
8 3.3V
9 NC
10 NC
11 NC
12 0V
13 1.7V
14 1.7V
15 0V
16 0V
17 1.17V
18 NC
19 NC
20 NC
21 NC
22 NC
23 NC
24 0V
4 PIN NO. VALUE
1 6V
2 6V
3 0V
4 0V
5 1.7V
6 1.7V
7 1.7V
8 0V
9 NC
10 NC
11 0V
12 3.3V
13 3.3V
14 3.3V
15 NC
16 3.3V
17 0V
18 0V
19 0V
20 0V
21 3.3V
22 0V
23 0V
24 0V
25 0V
26 3.3V
27 0V
28 3.3V
29 3.3V
30 3.3V
6 PIN NO. VALUE
1 3.3V
2 0V
3 3.3V
4 3.3V
5 0V
6 0V
XP5
CN207
XP6
XP114
XP13
XP113
2 PIN NO. VALUE
1 14.3V
2 14.3V
3 PIN NO. VALUE
1 3.3V/0V
2 0V
XP4
XP114
4 1
2 1
2 1
2 30
1 29
1 23
2 24
1 6
