Panasonic SC-HTB770 - Speaker Assembly - Wall Mounting (Horizontal); Securing Speakers to Wall Mounts

14
RQT9778
Wall mount the speakers:
Fit the speaker securely onto the screw(s).
Red connector: The speaker attached to the red connector cable is to be placed on the right side.
White connector: The speaker attached to the white connector cable is to be placed on the left side.
A Right speaker connector
B Left speaker connector
DO DO NOT
≥ Move the speaker so
that the screw is in this
position.
≥ In this position, the
speaker will likely fall if
moved to the left or
right.


Red
White
