Panasonic SC-HTB770 - Speaker Assembly - Wall Mounting (Vertical); Securing Speakers to Wall Mounts (Vertical)

18
RQT9778
Fit the speaker(s) securely onto the screw(s).
Red connector: The speaker attached to the red connector cable is to be placed on the right side.
White connector: The speaker attached to the white connector cable is to be placed on the left side.
A Left speaker connector B Right speaker connector
DO DO NOT
Front speaker Center speaker
Front speaker Center speaker
≥ Move the speaker so that the screw is in this position. ≥ In this position, the speaker will likely fall if moved to
the left or right.


Red
White
