RQT9778
17
Drive a screw into the wall.
≥ Use the measurements indicated below to identify the screwing positions on the wall.
≥ Leave at least 20 mm (
25
/32q) of space above and on each side of the speaker to allow enough space for fitting the speaker.
≥ Keep the screws out of reach of children to prevent swallowing.
Front speakers
A
At least 30 mm
(1
3
/
16
q
)
B ‰4.0 mm (
5
/32q)
C ‰7.0 mm to
‰9.4 mm
(
9
/32q to
3
/8q)
D Wall or pillar
E 5.5 mm to 6.5 mm
(
7
/32q to
1
/4q)
F Front speaker
(Rear view)
G 100 mm (3
15
/16q)
H 436 mm (17
5
/32q)
I 34 mm (1
11
/32q)
J Wall mounting hole
Center speaker
K At least 30 mm
(1
3
/16q)
L ‰4.0 mm (
5
/32q)
M ‰7.0 mm to
‰9.4 mm
(
9
/32q to
3
/8q)
N Wall or pillar
O 1.6 mm to 2.5 mm
(
1
/16q to
3
/32q)
P Max. 3.5 mm
(
9
/64q)
Q Center speaker
(Rear view)
R 18 mm (
23
/32q)
S 147 mm (5
25
/32q)
T 13 mm (
1
/2q)
U 19.6 mm (
25
/32q)
V 50.2 mm (1
31
/32q)
