Panasonic SC-HTB880 User Manual

Operations
RQT9904
23

≥ The default setting is underlined. Changed settings will be
kept until it is changed again, unless otherwise indicated.
You can view the current audio format.
Press and hold [SOUND] for more than 4 sec.
H.BASS
Enhance the harmonic
bass effect.
ON
OFF
3D CLR
DIALOG
The 3D Clear Mode Dialog
feature creates a sound field
similar to the sound coming
from a TV screen and
makes dialogues clearer.
ON: 3D Surround, Clear
Mode Dialog and Dolby
Virtual Speaker effect
OFF: Dolby Virtual
Speaker effect
The setting is set back to
“ON” every time you turn
the main unit on.
DUAL
AUDIO
Sets the preferred audio
channel mode when there
are two audio modes
received by this system.
M1
: Main
M2: Secondary
M1 + M2:
Main + Secondary
This effect only works if the
audio output of the TV or
player is set to “Bitstream”
and “Dolby Dual Mono” is
available in the sound source.
AGC
Auto gain control prevents
sudden loud sound by
reducing the sound level
automatically when the
input is too high.
This function is suitable for
TV broadcast that has
sound level difference.
ON
OFF
If the sound becomes
unnatural, select “OFF”.
LOW VOL
MODE
Enhance the dialog in low
volume condition.
ON
OFF
Select “OFF” to cancel this
effect if the dialog does not
sound natural in low
volume condition.
Audio format
DOLBY
DIGITAL
Dolby Digital is the audio
source.
DTS DTS is the audio source.
PCM MULTI
Linear pulse-code
modulation is the audio
source.
PCM
2 channel pulse-code
modulation is the audio
source.
SC-HTB880EB_RQT9904-B.book 23 ページ ２０１４年３月３日 月曜日 午前１０時２９分

Panasonic SC-HTB880 Specifications

General

RMS Power	500 watts
Outputs	hdmi
USB Ports	1
Bluetooth	yes
Wireless Subwoofer Connectivity	yes
Optical Audio Inputs	1
Remote Control	no

Weight and Dimensions

Depth	12.3 inches
Width	14.4 inches
Net Weight	24.55 pounds
