Panasonic SC-HTB880 User Manual

30
RQT9904
Specifications

§1 When the other connected devices are turned off.
AMPLIFIER SECTION
RMS output power: Dolby Digital Mode
Front ch (L, R ch)
50 W per channel (6 ≠), 1 kHz, 10 % THD
Centre ch (C ch)
50 W per channel (6 ≠), 1 kHz, 10 % THD
Surround ch (L, R ch)
50 W per channel (6 ≠), 1 kHz, 10 % THD
Subwoofer ch
250 W per channel (8 ≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power
500 W
TERMINAL SECTION
HDAVI Control
This unit supports “HDAVI Control 5” function.
HDMI AV input (BD/DVD, AUX)
2
Input connector
Type A (19 pin)
HDMI AV output (TV (ARC))
1
Output connector
Type A (19 pin)
Digital audio input (TV)
Optical digital input
Optical terminal
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only LPCM)
Audio format
LPCM, Dolby Digital, DTS Digital Surround
IR Blaster
Term in al Type
3.5 mm jack
USB Port
For service use only.
GENERAL
Power consumption
Main unit
33 W
Active subwoofer
46 W
In standby condition
Main unit
§1
When “BLUETOOTH STANDBY” is “OFF”
Approx. 0.49 W
When “BLUETOOTH STANDBY” is “ON”
Approx. 3.0 W
Active subwoofer
Power switch off
Approx. 0.2 W
The wireless link is not activated
Approx. 0.4 W
Power supply
AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
Main unit
For table top layout
1125 mmk51 mmk121 mm
For wall mounting layout
1125 mmk122.5 mmk56.5 mm
Active subwoofer
180 mmk408 mmk306 mm
Mass
Main unit
For table top layout
Approx. 3.1 kg
For wall mounting layout
Approx. 3.2 kg
Active subwoofer
Approx. 5.4 kg
Operating temperature range
0
o
C to i40
o
C
Operating humidity range
20 % to 80 % RH (no condensation)
SC-HTB880EB_RQT9904-B.book 30 ページ ２０１４年３月３日 月曜日 午前１０時２９分

Panasonic SC-HTB880 Specifications

General

RMS Power	500 watts
Outputs	hdmi
USB Ports	1
Bluetooth	yes
Wireless Subwoofer Connectivity	yes
Optical Audio Inputs	1
Remote Control	no

Weight and Dimensions

Depth	12.3 inches
Width	14.4 inches
Net Weight	24.55 pounds
