14
TQBM0479
The main unit can be wall mounted using the supplied wall mount brackets, etc. Make sure that the
screw used and the wall are strong enough to support the weight of at least 60 kg.
The screws and other items are not supplied as the type and size will vary with each installation.
≥ Refer to step 3 for details about the required screws.
≥ Be sure to attach the fall prevention cord as a secondary safety measure.
Supplied accessories
Additionally required accessories (commercially available)
≥ Screws for wall mounting............................................................................................................. k 2
≥ Fall prevention cord..................................................................................................................... k 2
≥ Screw eyes (to attach the fall prevention cord) ........................................................................... k 2

≥ Use a cord that is capable of supporting over 60 kg (with a diameter of about 1.5 mm).
≥ Lay the unit on a blanket or soft cloth for assembly.
1 Perform steps 1 in “When placing the main unit in a rack or on a table”. ( 13)
2 Attach the wall mount brackets to the main unit.
When attaching the main unit to a wall
∏ 2 Screws ∏ 2Wall mount
brackets
A Wall mount bracket (supplied)
B Screw (supplied)




(Rear)
SC-HTB900-EGEBGN-TQBM0479_eng.book 14 ページ ２０１９年４月１６日 火曜日 午後７時５８分

Panasonic SC-HTB900 Specifications

General

Game mode	Yes
RMS rated power	505 W
Audio output channels	3.1 channels
Wi-Fi	-
Bluetooth version	4.2
HDMI ports quantity	3
Connectivity technology	Wired
Impedance	4 Ω
Soundbar speaker RMS power	85 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	40 W
Power consumption (standby)	0.3 W
Product color	Black

Weight and Dimensions

Depth	129 mm
Width	1050 mm
Height	78 mm
Soundbar weight	6000 g
Subwoofer depth	306 mm
Subwoofer width	180 mm
Subwoofer height	408 mm
Subwoofer weight	5400 g
