Optional antenna connections
FM outdoor antenna DAB outdoor antenna
5SETHEANTENNA
PLUGADAPTOR
INCLUDED
FM outdoor antenna
(not included)
75
Ω coaxial cable
(not included)
Be sure to fully
tighten the screw.
DAB outdoor antenna
(not included)
• Never use an outdoor antenna during a lightning storm.
• You can connect the FM outdoor antenna for better reception. Please consult your dealer for installation.
• Disconnect the FM indoor antenna if an FM outdoor antenna is installed.
- Inserting batteries into the remote control
■ Batteries
• Insert so the poles (+ and –) match those in the remote control.
• Remove if the remote control is not going to be used for a long period of
time. Store in a cool, dark place.
• Do not use rechargeable type batteries.
• Mishandling of batteries in the remote control can cause electrolyte
leakage, which may cause a fi re.
Do not:
• mix old and new batteries;
• use different types of batteries at the same time;
• heat or expose to fl ame;
• take apart or short-circuit;
• attempt to recharge alkaline or manganese batteries;
• use batteries if their covering has been peeled off.
■ Use
Aim at the remote control sensor, avoiding obstacles, at a maximum
range of 7
m directly in front of the unit.
Refer to page 7 for remote control signal sensor position.
- DEMO function
When the unit is fi rst plugged in, a demonstration of its functions may be
shown on the display.
If the demo setting is off, you can show a demonstration by selecting
“DEMO ON”.
Press and hold [7, –DEMO].
The display changes each time the button is held down.
$%-//&& $%-//.
While in standby mode, select “DEMO OFF” to reduce power
consumption.
PM45DB_EB_EN.indd 6PM45DB_EB_EN.indd 6 3/6/07 5:50:57 PM3/6/07 5:50:57 PM
