11
VQT5J67
Reset the memory when the following situations occur:
• There is no response when buttons are pressed.
• You want to clear and reset the memory contents.
1 Disconnect the AC power supply cord.
Wait 3 minutes before you continue with step 2.
2 While you press and hold [Í/I] on the main unit,
connect the AC power supply cord again.
“- - - - - - - - - - - -” is shown.
3 Release [Í/I].
All the settings are set back to the factory preset.
It is necessary to set the memory items again.
When other Panasonic equipment responds to the remote
control of this system, change the remote control code for
this system.
To set the code to “Remote 2”
1 Press and hold [CD] on the main unit and [2] on the
remote control until “Remote 2” is shown.
2 Press and hold [OK] and [2] for a minimum of
4 seconds.
To set the code to “Remote 1”
1 Press and hold [CD] on the main unit and [1] on the
remote control until “Remote 1” is shown.
2 Press and hold [OK] and [1] for a minimum of
4 seconds.
Specifications
RMS output power
Front Ch (both ch driven)
60 W per channel (3 ™), 1 kHz,
10% total harmonic distortion
Total RMS power 120 W
FTC output power
Front Ch (both ch driven)
20 W per channel (3 ™), 50 Hz to 20 kHz,
1% total harmonic distortion
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.90 MHz to 107.90 MHz (200 kHz step)
87.50 MHz to 108.00 MHz (100 kHz step)
Antenna terminals 75 ™ (unbalanced)
“iPod_Port” connection
DC OUT 5 V 2.1 A (max)
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
USB device file system FAT12, FAT16, FAT32
ID3 Tag support v2.3
“iPod_Dock” connection
DC OUT 5 V 1.0 A (max)
Headphones jack Stereo, Ø 3.5 mm (
1
/
8
q) jack
AUX input Pin jack
Disc played [8 cm (3
q) or 12 cm (5q)]
CD, CD-R/RW (CD-DA, MP3)
Pick up
Wavelength 790 nm (CD)
Laser power CLASS 1
Audio output (Disc)
Number of channels 2 ch (FL, FR)
Speaker unit(s)
Woofer 14 cm (5
1
/2q) cone type x 1
Tweeter 1.9 cm
(
3
/4q) dome type x 1
Super tweeter 1.5 cm
(
19
/32q) piezo type x 1
Impedance 3™
Dimensions (W x H x D) 161 mm x 238 mm x 262 mm
(6
11
/
32
qk
9
3
/
8
qk
10
5
/
16
q
)
Mass (weight) Approx. 2.6 kg (5.7 lbs)
Bluetooth
®
system specification V3.0
Wireless equipment classification Class 2
Supported profiles A2DP, AVRCP
Frequency band 2.4 GHz band FH-SS
Driving distance 10 m
(33 ft) Line of sight
Prospective communication distance
Measurement environment:
Temperature 25 oC (77
o
F) / Height 1 m (3.3 ft)
Measure in “Mode 1”
Power supply AC 120 V, 60 Hz
Power consumption 60 W
Dimensions (main unit)
(W x H x D) 210 mm x 120 mm x 266 mm
(8
9
/
32
qk4
3
/
4
qk10
1
/
2
q
)
Mass (weight) (main unit) Approx. 3 kg
(6.6
lbs)
Operating temperature range 0°C to +40°C
(r32
o
F to r104
o
F)
Operating humidity range
35% to 80% RH (no condensation)
Note:
• Specifications are subject to change without notice. Mass
and dimensions are approximate.
• Total harmonic distortion is measured by the digital
spectrum analyzer.
Memory reset (initialisation)
Remote control code
Amplifier section
Tuner section
Terminals section
Disc section
Speaker section
Bluetooth
®
section
General
Power consumption in standby mode
(
When the iPod/iPhone/iPad is not charging)
0.2 W (approximate)
