Page #123 background imageLoading...
Page #123 background image
123
English
Corresponding signal Resolution (Dot)
Scanning frequency
Dot clock
frequency (MHz)
Format
*
3
Horizontal
(kHz)
Vertical (Hz)
1366 x 768/50 1 366 x 768 39.55 50.00 69.92 D/H/DL
1366 x 768/60 1 366 x 768 48.39 60.03 86.71 R/Y/D/H/DL
1366 x 768/60 1 366 x 768 48.00 60.00 72.00 R/Y/D/H/DL
1366 x 768/50 1 366 x 768 39.56 49.89 69.00 R/Y/D/H/DL
1366 x 768/60 1 366 x 768 47.71 59.79 85.50 R/Y/D/H/DL
1400 x 1050/60 1 400 x 1 050 65.22 60.00 122.61 D/H/DL
1400 x 1050/75 1 400 x 1 050 82.20 75.00 155.85 R/Y/D/H/DL
1440 x 900/60 1 440 x 900 55.47 59.90 88.75 R/Y/D/H/DL
1440 x 900/60 1 440 x 900 55.92 60.00 106.47 R/Y/D/H/DL
1600 x 900/50 1 600 x 900 46.30 50.00 97.05 D/H/DL
1600 x 900/60 1 600 x 900 60.00 60.00 108.00 D/H/DL
1600 x 900/60 1 600 x 900 55.99 59.95 118.25 D/H/DL
1600 x 900/60 1 600 x 900 55.92 60.00 119.00 D/H/DL
1680 x 1050/60 1 680 x 1 050 65.29 59.95 146.25 R/Y/D/H/DL
1600 x 1200/60 1 600 x 1 200
*
4
75.00 60.00 162.00 R/Y/D/H/DL
1920 x 1080/60 1 920 x 1 080
*
5
66.59 59.93 138.50 R/Y/D/H/DL
1920 x 1080/60 1 920 x 1 080 67.50 60.00 148.50 R/Y/D/H/DL
1920 x 1200/60 1 920 x 1 200
*
4
*
6
74.04 59.95 154.00 R/Y/D/H/DL
*
1: When 1035/60i signal is input, it is displayed as 1080/60i signal.
*
2: Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
*
3: Signals to represent formats are as follows.
V : Composite Video (AV IN)
R : D-sub RGB (PC IN)
Y : YP
BPR/YCBCR (PC IN)
D : DVI-D (DVI-D IN)
H : HDMI (HDMI 1, HDMI 2)
DL: DIGITAL LINK (DIGITAL LINK)
The analogue input supports onG and onY.
*
4: Displayed with image elements thinned out in the image processing circuit.
*
5: Based on VESA CVT-RB (Reduced Blanking) standard
*
6: Not supported when [DIGITAL LINK mode] is set to [Long reach].
Note
●
An auto detected signal format may be differently displayed from the actual input signal.
●
[ i ] shown after the number of dots of resolution means the interlace signal.
●
When 1080/30PsF signal and 1080/25PsF signal are input, they are processed as 1080/60i signal and 1080/50i
signal, and then displayed.
