23
English
●
Corresponding signal for DIGITAL LINK input is the
same as that of HDMI input. (see page 122)
●
For audio, it is also possible to use AV IN terminal
input. (For [Audio input select] function, see page 72.)
SERIAL IN / SERIAL OUT terminal
connection
The SERIAL terminal conforms to the RS-232C interface
specification, so that the Display can be controlled by a
computer which is connected to this terminal.
Note
●
Additional computer and cables shown are not
supplied with this set.
D-sub 9p
(Female)
(Male)
RS-232C Straight cable (commercially available)
PC
Note
●
Select the RS-232C straight cable for communication
used for connecting SERIAL terminal and computer
according to the computer you are using.
To Next Page
