Panasonic SF2H Series Operating Instructions (Functional Manual)

122
English
Preset Signals
This unit can display the video signals shown in the table below.
Corresponding signal Resolution (Dot)
Scanning frequency
Dot clock
frequency (MHz)
Format
*
3
Horizontal
(kHz)
Vertical (Hz)
NTSC/NTSC4.43/
PAL-M/PAL60
720 x 480i 15.73 59.94
V
PAL/PAL-N/SECAM 720 x 576i 15.63 50.00
V
480/60i 720 x 480i 15.73 59.94 13.50 R/Y
576/50i 720 x 576i 15.63 50.00 13.50 R/Y
480/60i 720 (1 440) x 480i
*
2
15.73 59.94 27.00 D/H/DL
576/50i 720 (1 440) x 576i
*
2
15.63 50.00 27.00 D/H/DL
480/60p 720 x 483 31.47 59.94 27.00 R/Y/D/H/DL
576/50p 720 x 576 31.25 50.00 27.00 R/Y/D/H/DL
720/60p 1 280 x 720 45.00 60.00 74.25 R/Y/D/H/DL
720/50p 1 280 x 720 37.50 50.00 74.25 R/Y/D/H/DL
1080/60i
*
1
1 920 x 1 080i 33.75 60.00 74.25 R/Y/D/H/DL
1080/50i 1 920 x 1 080i 28.13 50.00 74.25 R/Y/D/H/DL
1080/24p 1 920 x 1 080 27.00 24.00 74.25 R/Y/D/H/DL
1080/24PsF 1 920 x 1 080i 27.00 48.00 74.25 R/Y
1080/25p 1 920 x 1 080 28.13 25.00 74.25 R/Y/D/H/DL
1080/30p 1 920 x 1 080 33.75 30.00 74.25 R/Y/D/H/DL
1080/60p 1 920 x 1 080 67.50 60.00 148.50 R/Y/D/H/DL
1080/50p 1 920 x 1 080 56.25 50.00 148.50 R/Y/D/H/DL
640 x 400/70 640 x 400 31.47 70.09 25.18 R/Y/D/H/DL
640 x 400/85 640 x 400 37.86 85.08 31.50 R/Y/D/H/DL
640 x 480/60 640 x 480 31.47 59.94 25.18 R/Y/D/H/DL
640 x 480/67 640 x 480 35.00 66.67 30.24 R/Y/D/H/DL
640 x 480/73 640 x 480 37.86 72.81 31.50 R/Y/D/H/DL
640 x 480/75 640 x 480 37.50 75.00 31.50 R/Y/D/H/DL
640 x 480/85 640 x 480 43.27 85.01 36.00 R/Y/D/H/DL
800 x 600/56 800 x 600 35.16 56.25 36.00 R/Y/D/H/DL
800 x 600/60 800 x 600 37.88 60.32 40.00 R/Y/D/H/DL
800 x 600/72 800 x 600 48.08 72.19 50.00 R/Y/D/H/DL
800 x 600/75 800 x 600 46.88 75.00 49.50 R/Y/D/H/DL
800 x 600/85 800 x 600 53.67 85.06 56.25 R/Y/D/H/DL
832 x 624/75 832 x 624 49.72 74.55 57.28 R/Y/D/H/DL
852 x 480/60 852 x 480 31.47 59.94 34.24 D/H/DL
1024 x 768/50 1 024 x 768 39.55 50.00 51.89 D/H/DL
1024 x 768/60 1 024 x 768 48.36 60.00 65.00 R/Y/D/H/DL
1024 x 768/70 1 024 x 768 56.48 70.07 75.00 R/Y/D/H/DL
1024 x 768/75 1 024 x 768 60.02 75.03 78.75 R/Y/D/H/DL
1024 x 768/82 1 024 x 768 65.55 81.63 86.00 R/Y/D/H/DL
1024 x 768/85 1 024 x 768 68.68 85.00 94.50 R/Y/D/H/DL
1066 x 600/60 1 066 x 600 37.64 59.94 53.00 D/H/DL
1152 x 864/60 1 152 x 864 53.70 60.00 81.62 D/H/DL
1152 x 864/70 1 152 x 864 63.99 70.02 94.20 R/Y/D/H/DL
1152 x 864/75 1 152 x 864 67.50 75.00 108.00 R/Y/D/H/DL
1152 x 864/85 1 152 x 864 77.09 85.00 119.65 R/Y/D/H/DL
1152 x 870/75 1 152 x 870 68.68 75.06 100.00 R/Y/D/H/DL
1280 x 720/60 1 280 x 720 44.76 60.00 74.48 R/Y/D/H/DL
1280 x 768/50 1 280 x 768 39.55 49.94 65.18 R/Y/D/H/DL
1280 x 768/60 1 280 x 768 47.70 60.00 80.14 R/Y/D/H/DL
1280 x 768/60 1 280 x 768 47.78 59.87 79.50 R/Y/D/H/DL
1280 x 800/50 1 280 x 800 41.20 50.00 68.56 R/Y/D/H/DL
1280 x 800/60 1 280 x 800 49.31 59.91 71.00 R/Y/D/H/DL
1280 x 800/60 1 280 x 800 49.70 59.81 83.50 R/Y/D/H/DL
1280 x 960/60 1 280 x 960 60.00 60.00 108.00 R/Y/D/H/DL
1280 x 960/85 1 280 x 960 85.94 85.00 148.50 R/Y
1280 x 1024/60 1 280 x 1 024 63.98 60.02 108.00 R/Y/D/H/DL
1280 x 1024/75 1 280 x 1 024 79.98 75.02 135.00 R/Y/D/H/DL
1280 x 1024/85 1 280 x 1 024 91.15 85.02 157.50 R/Y/D/H/DL
1360 x 768/60 1 360 x 768 47.71 60.02 85.50 D/H/DL
1360 x 768/60 1 360 x 768 47.70 60.00 84.72 D/H/DL
1360 x 768/60 1 360 x 768 47.72 59.80 84.75 D/H/DL
