Panasonic TC-P54S1 Revised Troubleshooting Handbook

Slide #46
Warning: Disconnect AC Power prior to
making any disconnection or connection.
Preparation:
Disconnect AC Power prior to making any disconnection or connection.
Wait at least 2 minutes before the removal of any connector.
Note: If the power LED continues to blink even after the TV is unplugged, press and hold the power switch
on the TV for a few seconds until the LED turns off.
Remove the front cabinet and expose the panel to a bright light for a thorough visual inspection. Check for
cracks and blown pixels or any other abnormalities.
Check the ICs on the SU and SD boards for blown hole on the surface.
Note: In some models it is not possible to check if these ICs are blown because they use surface-mount
heat sinks that are glued to the surface of the ICs.
Trouble mode Defective Boards (Possibility)
SC Floating Section SOS SU, SD, SC, A, P, & Panel
7 Blinks Error Code (1 of 4)
LIST OF
MODELS:
All 2009 Models

Panasonic TC-P54S1 Specifications

General

Safety	UL6500/C-UL
Comb filter	3D
Pixel pitch	0.624 x 0.624 mm
Aspect ratio	16:9
Power supply	599 W
Product color	Black
Audio (L/R) in	2
Package weight	48000 g
Product weight	83.8 lbs
Noise reduction	Yes
RMS rated power	20 W
Display diagonal	54 \
Display language	English/Spanish/French
Set depth (inch)	4.2 \
Set width (inch)	51.7 \
Set height (inch)	32.8 \
Composite video in	1
Display technology	Plasma
Power requirements	AC 120 V, 60Hz
HDMI ports quantity	3
Remote control type	IR
Box depth (imperial)	13.1 \
Box width (imperial)	57.6 \
Box height (imperial)	37 \
Supported video modes	1080i, 1080p, 480p, 720p
Compatible memory cards	SDHC
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	-
Package weight (imperial)	105.8 lbs
Power consumption (sleep)	0.3 W
Operating temperature (T-T)	0 - 40 °C
Sustainability certificates	ENERGY STAR
Set depth (with stand) (inch)	15.3 \
Set height (with stand) (inch)	34.8 \
