45
Specifi cations
TH-37PWD8UK TH-42PWD8UK
Power Source 120 V AC, 50/60 Hz
Power Consumption
Maximum 250 W 275 W
Stand-by condition Save OFF 1.0 W, Save ON 0.7 W Save OFF 1.0 W, Save ON 0.7 W
Power off condition 0.05 W 0.05 W
Plasma Display panel Drive method : AC type 37-inch,
16:9 aspect ratio
Drive method : AC type 42-inch,
16:9 aspect ratio
Contrast Ratio 4000:1
Screen size 32” 13/64 (818mm) (W) × 18” 9/64 (461mm) (H)
× 36” 31/32 (939mm) (diagonal)
36” 7/32 (920mm) (W) × 20” 25/64 (518mm) (H)
× 41” 37/64 (1,056mm) (diagonal)
(No.of pixels) 408,960 (852 (W) × 480 (H))
[2,556 × 480 dots]
Operating condition
Temperature 32 °F - 104 °F (0 °C - 40 °C)
Humidity 20 % - 80 %
Applicable signals
Color System NTSC, PAL, PAL60, SECAM, Modifi ed NTSC
Scanning format 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 50i · 24p · 25p
· 30p · 24sF ···· SMPTE274M, 1250 (1080) / 50i
PC signals VGA
SVGA, XGA, SXGA, UXGA ···· (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
Connection terminals
AV VIDEO IN/OUT (BNC) 1.0 Vp-p (75-ohm or high impedance)
S VIDEO IN (MINI DIN 4PIN) Y: 1 Vp-p (75-ohm), C: 0.286 Vp-p (75-ohm)
AUDIO IN (RCA PIN JACK × 2) 0.5 Vrms (high impedance)
COMPONENT/RGB Y/G (BNC) 1.0 Vp-p/composite (75-ohm)
0.7 Vp-p/non-composite (75-ohm)
P
B/B (BNC), PR/R (BNC) 0.7 Vp-p (75-ohm)
AUDIO IN (RCA PIN JACK × 2) 0.5 Vrms (high impedance)
PC (HIGH-DENSITY D-SUB 15PIN) R,G,B/0.7 Vp-p (75-ohm)
Component
Y : 1.0 Vp-p (75-ohm : include sync)
P
B/CB : ± 0.7 Vp-p (75-ohm)
P
R/CR : ± 0.7 Vp-p (75-ohm)
HD, VD/1.0 - 5.0 Vp-p (high impedance)
AUDIO IN (M3 JACK) 0.5 Vrms (high impedance)
SERIAL EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE
SPEAKERS (6 ȍ) 16W [8 W + 8 W] (10 % THD)
Accessories Supplied
Remote Control Transmitter
EUR7636070R
Batteries 2 × AA Size
Fixing bands (TMME203 or TMME187) × 2
Dimensions (W × H × D)
36.2” (920 mm) × 21.7” (550 mm) × 3.5” (89 mm)
(exclusive of protruding portion)
40.2” (1,020 mm) × 24” (610 mm) × 3.5” (89 mm)
(exclusive of protruding portion)
Mass (weight)
main unit only approx. 55.1 lbs approx. 65.0 lbs
with speakers approx. 63.9 lbs approx. 73.9 lbs
Note:
Design and specifi cations are subject to change without notice. Mass and dimensions shown are approximate.
